UCC3895Q

Obsolete

Texas Instruments

RESONANT CONTROLLER 100MA 1000KHZ 20-PIN PLCC TUBE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

UCC3895Q

Obsolete

Texas Instruments

RESONANT CONTROLLER 100MA 1000KHZ 20-PIN PLCC TUBE

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	UCC3895Q

Clock Sync	True
Control Features	Frequency Control, Soft Start, Sync
Duty Cycle (Max) [Max]	100 %
Frequency - Switching	1 MHz
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Output Configuration	Positive
Output Phases	1
Package / Case	20-LCC (J-Lead)
Supplier Device Package	20-PLCC (9x9)
Topology	Phase-Shifted Full-Bridge
Voltage - Supply (Vcc/Vdd) [Max]	16.5 V
Voltage - Supply (Vcc/Vdd) [Min]	10 V

UCC3895 Series

Part	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Package / Case [y]	Package / Case	Package / Case [x]	Duty Cycle (Max) [Max]	Operating Temperature [Max]	Frequency - Switching	Output Phases	Control Features	Number of Outputs	Topology	Mounting Type	Output Configuration	Supplier Device Package	Package / Case	Package / Case	Package / Case [y]
Texas Instruments UCC3895PWTR	16.5 V	10 V	4.4 mm	20-TSSOP	0.173 in	100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-TSSOP
Texas Instruments UCC3895N	16.5 V	10 V		20-DIP		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Through Hole	Positive	20-PDIP	7.62 mm	0.3 in
Texas Instruments UCC3895DWG4	16.5 V	10 V	0.295 in	20-SOIC		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-SOIC			7.5 mm
Texas Instruments UCC3895DWTRG4	16.5 V	10 V	0.295 in	20-SOIC		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-SOIC			7.5 mm
Texas Instruments UCC3895DWTR	16.5 V	10 V	0.295 in	20-SOIC		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-SOIC			7.5 mm
Texas Instruments UCC3895Q	16.5 V	10 V		20-LCC (J-Lead)		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-PLCC (9x9)
Texas Instruments UCC3895PW	16.5 V	10 V	4.4 mm	20-TSSOP	0.173 in	100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-TSSOP
Texas Instruments UCC3895QG3	16.5 V	10 V		20-LCC (J-Lead)		100 %	70 °C	1 MHz	1	Frequency Control Soft Start Sync	1	Phase-Shifted Full-Bridge	Surface Mount	Positive	20-PLCC (9x9)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

UCC3895 Series

Phase-Shifted Full-Bridge Regulator Positive Output DC-DC Controller IC 20-PLCC (9x9)

Documents

Technical documentation and resources
