CONN SPADE TERM #6

Search across all available documentation for this part.

Active

Molex

CONN SPADE TERM #6

Technical Specifications

Parameters and characteristics for this part

Part	Stud/Tab Size	Insulation	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Mounting Type	Terminal Type	Termination	Wire Gauge [Max]	Wire Gauge [Min]	Length - Overall [x]	Length - Overall [x]	Contact Finish	Width - Outer Edges [y]	Width - Outer Edges [y]	Contact Material	Color	Length - Termination	Length - Termination	Material - Insulation	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Length - Ring Center to Termination [x]	Length - Ring Center to Termination [x]
Molex 0191370009	6 Stud	Insulated
Molex 0191370005	6 Stud	Insulated
Molex 0191370008	4 Stud	Insulated
Molex 0191370038	6 Stud	Insulated	5.72 mm	0.225 "	Free Hanging (In-Line)	Standard	Crimp	12 AWG	10 AWG	30.58 mm	1.204 in	Electro-Tin	8.13 mm	0.32 in	Copper	Yellow	16.99 mm	0.669 in	Nylon Polyamide (PA)	3.71 mm	0.146 in	0.305 "	7.75 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6 Stud Spade Terminal Connector
