UC385 LINEAR REGULATOR 1.2V OUTPUT EVALUATION BOARD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsUC285-1/2/3/ADJ, UC385-1/2/3/ADJ Datasheet

UC385EVM-207

Obsolete

Texas Instruments

UC385 LINEAR REGULATOR 1.2V OUTPUT EVALUATION BOARD

Deep-Dive with AI

DocumentsUC285-1/2/3/ADJ, UC385-1/2/3/ADJ Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	UC385EVM-207

Board Type	Fully Populated
Channels per IC	1 - Single
Current - Output	5 A
Regulator Type	Positive Adjustable
Supplied Contents	Board(s)
Utilized IC / Part	UC385
Voltage - Input [Max]	7.5 V
Voltage - Input [Min]	1.7 V
Voltage - Output	1.2 V

UC385 Series

Part	Number of Regulators	Voltage - Input (Max) [Max]	Package / Case	Output Configuration	Supplier Device Package	Current - Output	Voltage - Output (Min/Fixed)	Output Type	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Protection Features	Output Type	Regulator Type	Channels per IC	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Output	Supplied Contents	Utilized IC / Part	Board Type
Texas Instruments UC385T-2	1	7.5 V	TO-220-5	Positive	TO-220-5	5 A	2.1 V	1.81 mOhm	0 °C	100 °C	Through Hole	Over Temperature Reverse Polarity Short Circuit
Texas Instruments UC385TDTR-ADJ	1	7.5 V	D2PAK (5 Leads + Tab) TO-263-6 TO-263BA	Positive	TO-263 (DDPAK-5)	5 A	1.2 V		0 °C	100 °C	Surface Mount	Over Temperature Reverse Polarity Short Circuit	Adjustable (Fixed)
Texas Instruments UC385TDKTTT-ADJG3	1	7.5 V	D2PAK (5 Leads + Tab) TO-263-6 TO-263BA	Positive	TO-263 (DDPAK-5)	5 A	1.2 V		0 °C	100 °C	Surface Mount	Over Temperature Reverse Polarity Short Circuit	Adjustable (Fixed)
Texas Instruments UC385TDTR-3	1	7.5 V	D2PAK (5 Leads + Tab) TO-263-6 TO-263BA	Positive	TO-263 (DDPAK-5)	5 A	2.5 V	1.81 mOhm	0 °C	100 °C	Surface Mount	Over Temperature Reverse Polarity Short Circuit
Texas Instruments UC385TDKTTT-2	1	7.5 V	D2PAK (5 Leads + Tab) TO-263-6 TO-263BA	Positive	TO-263 (DDPAK-5)	5 A	2.1 V	1.81 mOhm	0 °C	100 °C	Surface Mount	Over Temperature Reverse Polarity Short Circuit
Texas Instruments UC385EVM-207						5 A								Positive Adjustable	1 - Single	7.5 V	1.7 V	1.2 V	Board(s)	UC385	Fully Populated
