TLS805B1LDV33XUMA1

Obsolete

Infineon Technologies

IC REG LIN 3.3V 50MA TSON-10-2

Search across all available documentation for this part.

Obsolete

Infineon Technologies

IC REG LIN 3.3V 50MA TSON-10-2

Technical Specifications

Parameters and characteristics for this part

Specification	TLS805B1LDV33XUMA1

Control Features	Enable
Current - Output	50 mA
Current - Quiescent (Iq)	8 ÁA
Current - Supply (Max) [Max]	12 µA
Grade	Automotive
Mounting Type	Wettable Flank, Surface Mount
Number of Regulators	1
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Output Configuration	Positive
Output Type	1.81 mOhm
Package / Case	10-TFDFN Exposed Pad
Protection Features	Over Current, Over Temperature
PSRR	60 dB
Qualification	AEC-Q100
Supplier Device Package	PG-TSON-10-2
Voltage - Input (Max) [Max]	42 V
Voltage - Output (Min/Fixed)	3.3 V
Voltage Dropout (Max) [Max]	0.35 V

Part	Channels per IC	Utilized IC / Part	Current - Output	Board Type	Regulator Type	Supplied Contents	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Output (Min/Fixed)	Number of Regulators	Package / Case	Output Configuration	Current - Quiescent (Iq)	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Qualification	Output Type	Mounting Type	Control Features	PSRR	Voltage - Input (Max) [Max]	Current - Supply (Max) [Max]	Grade	Protection Features	Voltage Dropout (Max) [Max]	Voltage - Output (Max) [Max]	Output Type
Infineon Technologies TLS805B1LDVBOARDTOBO1	1 - Single	TLS805B1	50 mA	Fully Populated	Positive Adjustable	Board(s)	42 V	3 V
Infineon Technologies TLS805B1LDV33XUMA1			50 mA						3.3 V	1	10-TFDFN Exposed Pad	Positive	8 ÁA	PG-TSON-10-2	150 °C	-40 °C	AEC-Q100	1.81 mOhm	Surface Mount Wettable Flank	Enable	60 dB	42 V	12 µA	Automotive	Over Current Over Temperature	0.35 V
Infineon Technologies TLS805B1LDVXUMA1			50 mA						1.2 V	1	10-TFDFN Exposed Pad	Positive	1 µA	PG-TSON-10	150 °C	-40 °C	AEC-Q100		Surface Mount	Enable	60 dB	42 V	11 µA	Automotive	Over Current Over Temperature Short Circuit	0.3 V	41.7 V	Adjustable

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Linear Voltage Regulator IC Positive Fixed 1 Output 50mA PG-TSON-10-2
