Specification	88-00158-97

For Use With/Related Products	SN8205UFL
Frequency	2.4 GHz
Supplied Contents	Cable(s), Board(s)
Type	Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN)

88-001 Series

Part	Supplied Contents	Type	For Use With/Related Products	Frequency	Operating Temperature [Max]	Operating Temperature [Min]	Utilized IC / Part	Memory Size	Data Rate	Serial Interfaces	Protocol	RF Family/Standard	Mounting Type	Power - Output	Current - Receiving	Package / Case	Antenna Type	Current - Transmitting [Max]	Current - Transmitting [Min]	Modulation	Voltage - Supply [Max]	Voltage - Supply [Min]	Current - Transmitting	Sensitivity
Murata Power Solutions Inc. 88-00153-85	Board(s)	Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN)	SN8000	2.4 GHz
Murata Power Solutions Inc. 88-00158-00				2.4 GHz	85 °C	-40 °C	BCM43362	1 MB 128 kB	65 Mbps	I2C I2S SPI UART	802.11b/g/n	WiFi	Surface Mount	18 dBm	110 mA	Module	Integrated Chip	370 mA	280 mA	CCK DSSS	3.6 V	2 V
Murata Power Solutions Inc. 88-00153-00				2.4 GHz	85 °C	-40 °C	BCM43362		65 Mbps	JTAG SDIO SPI	802.11b/g/n	WiFi	Surface Mount	18.5 dBm	70 mA	Module	Integrated Chip	315 mA	225 mA	CCK DSSS OFDM	4 V	3 V
Murata Power Solutions Inc. 88-00158-95	Board(s) Cable(s)	Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN)	SN8205	2.4 GHz
Murata Power Solutions Inc. 88-00158-97	Board(s) Cable(s)	Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN)	SN8205UFL	2.4 GHz
Murata Power Solutions Inc. 88-00153-87	Board(s)	Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN)	SN8000UFL	2.4 GHz
Murata Power Solutions Inc. 88-00154-00				2.4 GHz 5 GHz	85 °C	-40 °C	WL1857		65 Mbps		Bluetooth v4.0	Bluetooth	Surface Mount	15 dBm	57 mA	62-SMD Module	Integrated Trace				4.2 V	3 V	408 mA	-90 dBm
Murata Power Solutions Inc. 88-00151-95	Board(s) Cable(s)	Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN)	SN8200	2.4 GHz
