ZX62D1-B-5PA(30)
ActiveHirose Electric USA, Inc.
MICRO USB CONN, R/A PLUG, 5POS, SMT ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
ZX62D1-B-5PA(30)
ActiveHirose Electric USA, Inc.
MICRO USB CONN, R/A PLUG, 5POS, SMT ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ZX62D1-B-5PA(30) |
|---|---|
| Connector Type | USB - micro B |
| Contact Finish | Gold |
| Current Rating (Amps) | 1.8 A |
| Features | Pick and Place Cap, Solder Retention |
| Gender | Receptacle |
| Insulation Color | Black |
| Material Flammability Rating | UL94 V-0 |
| Mating Cycles | 10000 |
| Mounting Type | Through Hole, Surface Mount, Right Angle |
| Number of Contacts | 5 |
| Number of Ports | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -30 ░C |
| Shell/Shielding Material | Stainless, Steel |
| Shielding | Shielded |
| Specifications | USB 2.0 |
| Termination | Solder |
| Voltage - Rated | 30 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.79 | |
| 10 | $ 0.67 | |||
| 25 | $ 0.63 | |||
| 50 | $ 0.60 | |||
| 100 | $ 0.57 | |||
| 250 | $ 0.53 | |||
| 500 | $ 0.51 | |||
| 1000 | $ 0.48 | |||
| Digi-Reel® | 1 | $ 0.79 | ||
| 10 | $ 0.67 | |||
| 25 | $ 0.63 | |||
| 50 | $ 0.60 | |||
| 100 | $ 0.57 | |||
| 250 | $ 0.53 | |||
| 500 | $ 0.51 | |||
| 1000 | $ 0.48 | |||
| Tape & Reel (TR) | 3000 | $ 0.45 | ||
| 6000 | $ 0.42 | |||
| 9000 | $ 0.41 | |||
| 15000 | $ 0.40 | |||
| 21000 | $ 0.39 | |||
| Newark | Each (Supplied on Cut Tape) | 10 | $ 0.56 | |
| 100 | $ 0.51 | |||
| 250 | $ 0.46 | |||
| 500 | $ 0.42 | |||
| 1000 | $ 0.39 | |||
| 2500 | $ 0.36 | |||
| 5000 | $ 0.35 | |||
Description
General part information
ZX62 Series
USB - micro B USB 2.0 Receptacle Connector 5 Position Surface Mount, Right Angle; Through Hole
