SV 80 - SV 70

SV 80

Active
LUMBERG AUTOMATION

DIN AUDIO / VIDEO CONNECTOR, 8 CONTACTS, PLUG, PANEL MOUNT, SOLDER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetTechnical Data Sheet EN+1
SV 80 - SV 70

SV 80

Active
LUMBERG AUTOMATION

DIN AUDIO / VIDEO CONNECTOR, 8 CONTACTS, PLUG, PANEL MOUNT, SOLDER

Deep-Dive with AI

DocumentsDatasheetTechnical Data Sheet EN+1

Technical Specifications

Parameters and characteristics for this part

SpecificationSV 80
ColorSilver
Connector TypePlug, Male Pins
Contact Finish - MatingSilver, Gold
FeaturesStrain Relief
Ingress ProtectionIP40
Material Flammability RatingUL94
Mounting TypeFree Hanging (In-Line), Cable Mount
Number of Positions8
Operating Temperature [Max]85 °C
Operating Temperature [Min]-40 °C
Primary MaterialMetal
Shell FinishNickel
Shell MaterialZinc Alloy
Shell Size - InsertM16
TerminationSolder

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 13.38
10$ 10.28
100$ 8.02
1000$ 6.38
NewarkEach 1$ 9.74
10$ 9.35
25$ 8.77
50$ 8.18
100$ 7.50

Description

General part information

- Series

8 Position Circular Connector Plug, Male Pins Solder
