012520PW050

Active

Essentra Access Solutions

PAN SLOTTED SCREW, NATURAL, NYLO

Search across all available documentation for this part.

Active

Essentra Access Solutions

PAN SLOTTED SCREW, NATURAL, NYLO

Technical Specifications

Parameters and characteristics for this part

Part	Thread Size	Length - Overall	Length - Overall	Head Height	Head Height	Type	Material	Screw Head Type	Length - Below Head	Length - Below Head	Length - Below Head	Drive Type	Head Diameter [diameter]	Head Diameter [diameter]	Length - Overall [x]	Length - Overall [x]	Length - Below Head [x]	Length - Below Head [x]	Length - Below Head
Essentra Access Solutions 012520PW037	1/4"-20	14.55 mm	0.573 "	0.198 "	5.03 mm	Machine Screw	Nylon	Pan Head	0.375 "	9.53 mm	0.375 "	Phillips
Essentra Access Solutions 012520PW200	1/4"-20			0.198 "	5.03 mm	Machine Screw	Nylon	Pan Head				Phillips
Essentra Access Solutions 012520PW025	1/4"-20			0.198 "	5.03 mm	Machine Screw	Nylon	Pan Head	0.25 in	0.25 in	6.35 mm	Phillips	12.26 mm	0.483 in	11.38 mm	0.448 in
Essentra Access Solutions 012520PW250	1/4"-20			0.198 "	5.03 mm	Machine Screw	Nylon	Pan Head				Phillips	12.26 mm	0.483 in			63.5 mm	2.5 in
Essentra Access Solutions 012520PW150	1/4"-20			0.198 "	5.03 mm	Machine Screw	Nylon	Pan Head			38.1 mm	Phillips						1.5 in
Essentra Access Solutions 012520PW050	1/4"-20			0.198 "	5.03 mm		Nylon	Pan Head	0.5 in		12.7 mm	Phillips	12.27 mm	0.483 in	17.73 mm	0.698 in			1/2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1/4"-20 Pan Head Phillips Drive Nylon
