U7139-030PA-5W0000

Active

TE Connectivity Measurement Specialties

SENSOR

Search across all available documentation for this part.

Active

TE Connectivity Measurement Specialties

SENSOR

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Port Style	Features	Output [Min]	Output [Max]	Port Size [custom]	Port Size [x]	Port Size [x]	Port Size [custom]	Output Type	Package / Case	Applications	Accuracy	Operating Temperature [Max]	Operating Temperature [Min]	Maximum Pressure [Max]	Maximum Pressure [Max]	Operating Pressure	Operating Pressure	Termination Style	Port Size	Port Size	Maximum Pressure	Maximum Pressure	Pressure Type
TE Connectivity Measurement Specialties U7139-030PA-5W0000	4.75 V	5.25 V	Threaded	Temperature Compensated	0.5 V	4.5 V	NPT	0.25 "	6.35 mm	Male	Analog Voltage	Cylinder	Industrial Automation	0.25 %	125 °C	-40 °C	90 PSI	620.53 kPa	206.84 kPa	30 PSI	Connector
TE Connectivity Measurement Specialties U7139-002BA-2W0000	4.75 V	5.25 V	Threaded	Temperature Compensated	0.5 V	4.5 V					Analog Voltage	Cylinder	Industrial Automation	0.25 %	125 °C	-40 °C			2 bar	29.01 PSI	Connector	BSPP Male	6.35 mm	87.02 PSI	600 kPa
TE Connectivity Measurement Specialties U7139-010BA-2W0000	4.75 V	5.25 V	Threaded	Temperature Compensated	0.5 V	4.5 V					Analog Voltage	Cylinder	Industrial Automation	0.25 %	125 °C	-40 °C			10 bar	145.04 PSI	Connector	BSPP Male	6.35 mm	435.11 PSI	3000 kPa
TE Connectivity Measurement Specialties U7139-150PG-5W0000	4.75 V	5.25 V	Threaded	Temperature Compensated	0.5 V	4.5 V	NPT	0.25 "	6.35 mm	Male	Analog Voltage	Cylinder		0.25 %	125 °C	-40 °C	300 PSI	2068.43 kPa	1034.21 kPa	150 PSI	Connector					Vented Gauge

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 287.99

General part information

SENSOR

Technical documentation and resources
