05586.15.08
ActivePrysmian Group
CABLE 6COND 18AWG BROWN 100'
Deep-Dive with AI
Search across all available documentation for this part.
05586.15.08
ActivePrysmian Group
CABLE 6COND 18AWG BROWN 100'
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 05586.15.08 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Jacket (Insulation) Diameter [diameter] | 0.208 in |
| Jacket (Insulation) Diameter [diameter] | 5.28 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.203 mm |
| Jacket (Insulation) Thickness | 0.008 in |
| Jacket Color | Brown |
| Length | 15.24 m, 76.2 m |
| Length | 3000 " |
| Length [x] | 50 ft, 100 ft |
| Length [x] | 30.5 m |
| Number of Conductors | 6 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Voltage | 150 V |
| Wire Gauge | 18 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 63.30 | |
| 1 | $ 120.94 | |||
| 5 | $ 98.95 | |||
| 5 | $ 51.79 | |||
| 10 | $ 76.96 | |||
| 10 | $ 40.28 | |||
| Spool | 1000 | $ 0.51 | ||
Description
General part information
05586 Series
6 Conductor Multi-Conductor Cable Brown 18 AWG 100.0' (30.5m)
Documents
Technical documentation and resources
No documents available
