DCP-HDMIB-HD

Obsolete

Conxall/Switchcraft

ADAPTER HDMI RCPT TO RECT HDR

Search across all available documentation for this part.

Obsolete

Conxall/Switchcraft

ADAPTER HDMI RCPT TO RECT HDR

Technical Specifications

Parameters and characteristics for this part

Part	Convert To (Adapter End)	Convert From (Adapter End)	Ingress Protection	Contact Finish	Shielding	Number of Ports	Material Flammability Rating	Mating Cycles	Current Rating (Amps)	Shell/Shielding Material	Operating Temperature [Min]	Operating Temperature [Max]	Features	Number of Contacts [custom]	Termination	Connector Type	Gender	Mounting Feature
Conxall/Switchcraft DCP-HDMIB-HD	Rectangular Header	HDMI Receptacle
Conxall/Switchcraft DCP-HDMIB-SC			IP67/IP68 - Dust Tight Waterproof	Gold	Unshielded	1	UL94 V-0	350	0.5 A	Copper Alloy	-20 C	80 C	Circular Bayonet Coupling	19	PC Board	HDMI	Receptacle	Flange

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Adapter Connector HDMI, Receptacle To Rectangular Header Panel Mount

Technical documentation and resources

No documents available
