NCS3S4803SC

Active

Murata Power Solutions Inc.

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, 4:1, 3 W, 1 OUTPUT, 3.3 V, 700 MA

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, 4:1, 3 W, 1 OUTPUT, 3.3 V, 700 MA

Technical Specifications

Parameters and characteristics for this part

Isolated DC/DC Converters - Through Hole DC/DC TH 3W 48V-3.3V

Part	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Voltage - Isolation	Mounting Type	Applications	Voltage - Input (Max) [Max]	Power (Watts)	Features	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Number of Outputs	Voltage - Input (Min) [Min]	Voltage - Output 1	Type	Efficiency
Murata Power Solutions Inc. NCS3S1205SC	600 mA	85 °C	-40 °C	8-DIP Module 6 Leads	1.5 kV	Through Hole	ITE (Commercial)	36 V	3 W	SCP	11.3 mm	22 mm	0.44 "	9.5 mm	0.37 "	0.86 in	1	9 V	5 V	Isolated Module
Murata Power Solutions Inc. NCS3S4803SC	700 mA	85 °C	-40 °C	8-DIP Module 6 Leads	1.5 kV	Through Hole	ITE (Commercial)	75 V	3 W	SCP	11.3 mm	22 mm	0.44 "	9.5 mm	0.37 "	0.86 in	1	18 V	3.3 V	Isolated Module	74 %
Murata Power Solutions Inc. NCS3S4805SC	600 mA	85 °C	-40 °C	8-DIP Module 6 Leads	1.5 kV	Through Hole	ITE (Commercial)	75 V	3 W	SCP	11.3 mm	22 mm	0.44 "	9.5 mm	0.37 "	0.86 in	1	18 V	5 V	Isolated Module	80 %
Murata Power Solutions Inc. NCS3S4815SC	200 mA	85 °C	-40 °C	8-DIP Module 6 Leads	1.5 kV	Through Hole	ITE (Commercial)	75 V	3 W	SCP	11.3 mm	22 mm	0.44 "	9.5 mm	0.37 "	0.86 in	1	18 V	15 V	Isolated Module	83 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated DC/DC Converters - Through Hole DC/DC TH 3W 48V-3.3V
