ERA.4S.312.CLL

Active

LEMO

RECEPTACLE 20POS SLDR CUP

Deep-Dive with AI

Search across all available documentation for this part.

ERA.4S.312.CLL

Active

LEMO

RECEPTACLE 20POS SLDR CUP

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ERA.4S.312.CLL

Color	Silver
Connector Type	Female Sockets, Male Pins, Receptacle
Contact Finish - Mating	Gold
Contact Material	Bronze, Brass
Current Rating (Amps)	9 A
Fastening Type	Push-Pull
Ingress Protection	IP50
Insert Material	Polyetheretherketone (PEEK)
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Number of Positions	12
Operating Temperature [Max]	250 °C
Operating Temperature [Min]	-55 °C
Orientation	A
Primary Material	Metal
Shell Finish	Chrome
Shell Material	Brass
Shell Size - Insert	312
Shielding	Shielded

ERA.4S Series

Circular Push Pull Connectors

Part	Contact Material	Shell Finish	Color	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Shell Material	Material Flammability Rating	Fastening Type	Insert Material	Current Rating (Amps)	Orientation	Number of Positions	Primary Material	Connector Type	Contact Finish - Mating	Mounting Feature	Ingress Protection	Center Contact Material	Mating Cycles	Center Contact Plating	Impedance	Includes	Number of Ports	Dielectric Material	Body Material	Body Finish	Shield Termination	Connector Style	Housing Color	Cable Group	Contact Termination
LEMO ERA.4S.308.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	308	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)	13 A	Keyed	8	Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.250.CTL					-55 °C	250 °C				Push-Pull						Female Socket Receptacle		Bulkhead - Rear Side Nut	IP50	Beryllium Copper	1000	Gold	50 Ohms	1 Connector 1 Lockwasher 1 Nut	1	Polytetrafluoroethylene (PTFE)	Brass	Chrome	Solder	Coaxial	Silver	115A 144 165 213 214 216 225 RG-11A	Solder Cup
LEMO ERA.4S.140.CTL	Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	140	Brass		Push-Pull	Polytetrafluoroethylene (PTFE)	46 A	Keyed	1	Metal	Receptacle Female Sockets	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.302.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	302	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)	35 A	Keyed	2	Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.310.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	310	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)	11 A	Keyed	10	Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.305.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	305	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)		Keyed		Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.309.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	309	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)	12 A	Keyed	9	Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.312.CLL	Brass Bronze	Chrome	Silver	Shielded	-55 °C	250 °C	312	Brass	UL94 V-0	Push-Pull	Polyetheretherketone (PEEK)	9 A	A	12	Metal	Female Sockets Male Pins Receptacle	Gold	Bulkhead - Rear Side Nut	IP50
LEMO ERA.4S.230.LN

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 126.54
		10	$ 116.12
		25	$ 111.66
		50	$ 107.93

Description

General part information

ERA.4S Series

Circular Push Pull Connectors

Documents

Technical documentation and resources

No documents available
