8-03PMMS-SF7001
ActiveAmphenol LTW
SENSOR CONNECTOR, M SERIES, M8, PLUG, 3 CONTACTS, SOLDER PIN, STRAIGHT PANEL MOUNT
Deep-Dive with AI
Search across all available documentation for this part.
8-03PMMS-SF7001
ActiveAmphenol LTW
SENSOR CONNECTOR, M SERIES, M8, PLUG, 3 CONTACTS, SOLDER PIN, STRAIGHT PANEL MOUNT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 8-03PMMS-SF7001 |
|---|---|
| Color | Silver |
| Connector Type | Receptacle, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 3 A |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Polyamide (PA), Nylon, Glass Filled |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Orientation | Keyed |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Zinc Alloy |
| Shell Size - Insert | M8-3 |
| Shielding | Shielded |
| Voltage Rating | 60 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 6.14 | |
| 10 | $ 5.57 | |||
| 30 | $ 5.28 | |||
| 50 | $ 5.15 | |||
| 100 | $ 4.91 | |||
| 250 | $ 4.30 | |||
| 500 | $ 4.17 | |||
| 1000 | $ 3.56 | |||
| 2500 | $ 3.31 | |||
Description
General part information
8-03PMMS Series
3 Position Circular Connector Receptacle, Male Pins Solder Cup
