TS2P2M20 - TS2P2M20

TS2P2M20

Active
Switchcraft Inc.

CONN RCPT MALE 2POS GOLD CRIMP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet
TS2P2M20 - TS2P2M20

TS2P2M20

Active
Switchcraft Inc.

CONN RCPT MALE 2POS GOLD CRIMP

Deep-Dive with AI

DocumentsDatasheet

Technical Specifications

Parameters and characteristics for this part

SpecificationTS2P2M20
ApplicationsAudio, Testing Equipment & Measurement, Agriculture, Medical, General
ColorSilver
Connector TypeReceptacle, Male Pins
Contact Finish - MatingGold
Contact MaterialCopper Alloy
Ingress ProtectionIP68, IP66, IP67
Insert MaterialLiquid Crystal Polymer (LCP)
Mounting FeatureBulkhead - Rear Side Nut
Number of Positions2
Operating Temperature [Max]135 °C
Operating Temperature [Min]-40 °C
OrientationKeyed
Primary MaterialMetal
Shell FinishElectroless Nickel
Shell MaterialCopper Alloy
ShieldingShielded
TerminationCrimp, Solder Cup
Voltage Rating125 VAC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 11.54
10$ 8.88
25$ 8.03
50$ 7.90

Description

General part information

TS2P2M Series

2 Position Circular Connector Receptacle, Male Pins Crimp or Solder Cup

Documents

Technical documentation and resources

Datasheet

Datasheet
