PTH05030WAD
ObsoleteARTESYN / Advanced Energy
MODULE DC-DC 5VIN 1-OUT 0.8V TO 3.6V 30A 108W 13-PIN TRAY
Deep-Dive with AI
Search across all available documentation for this part.
PTH05030WAD
ObsoleteARTESYN / Advanced Energy
MODULE DC-DC 5VIN 1-OUT 0.8V TO 3.6V 30A 108W 13-PIN TRAY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PTH05030WAD |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 30 A |
| Efficiency | 94 % |
| Features | SCP, OTP, Remote On/Off, UVLO |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Power (Watts) | 108 W |
| Size / Dimension [x] | 34.8 mm |
| Size / Dimension [x] | 1.37 in |
| Size / Dimension [y] | 1.12 in |
| Size / Dimension [y] | 28.4 mm |
| Size / Dimension [z] | 0.35 " |
| Size / Dimension [z] | 8.9 mm |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) [Max] | 5.5 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Output 1 [Max] | 3.6 V |
| Voltage - Output 1 [Min] | 0.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
PTH05030 Series
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.6V 30A 4.5V - 5.5V Input
Documents
Technical documentation and resources
No documents available
