97-3102A-24-5S
ActiveAmphenol Industrial Operations
CONN RCPT FMALE 16P SOLDER CUP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
97-3102A-24-5S
ActiveAmphenol Industrial Operations
CONN RCPT FMALE 16P SOLDER CUP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 97-3102A-24-5S |
|---|---|
| Applications | Industrial, Automotive |
| Color | Olive Drab |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish - Mating | Silver |
| Contact Material | Copper Alloy |
| Insert Material | Diallyl Phthalate (DAP) |
| Mounting Feature | Flange |
| Number of Positions | 16 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Orientation | N |
| Primary Material | Metal |
| Shell Finish | Olive Drab Chromate over Cadmium |
| Shell Material | Aluminum Alloy |
| Shell Size - Insert | 24-5 |
| Shielding | Unshielded |
97-3102A24 Series
| Part | Shell Material | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Primary Material | Insert Material | Shielding | Mounting Feature | Orientation | Shell Finish | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Number of Positions | Color | Contact Material | Connector Type | Contact Finish - Mating | Shell Size - Insert | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | 24 | 10 | 7 | Olive Drab | Copper Alloy | Male Pins Receptacle | Silver | ||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | 12 | Olive Drab | Copper Alloy | Receptacle Female Sockets | Silver | 24-19 | |||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Black Zinc Alloy | 24 | 28 | 24 | Black | Copper Alloy | Male Pins Receptacle | Silver | ||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | Olive Drab | Copper Alloy | Receptacle Female Sockets | Silver | 24-5 | 16 | |||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | Olive Drab | Copper Alloy | Male Pins Receptacle | Silver | 24-5 | 16 | |||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | 12 | Olive Drab | Copper Alloy | Male Pins Receptacle | Silver | 24-19 | |||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | W | Olive Drab Chromate over Cadmium | 24 | 28 | 24 | Olive Drab | Copper Alloy | Receptacle Female Sockets | Silver | ||
Amphenol Industrial Operations | Aluminum Alloy | Automotive Industrial | -55 °C | 125 °C | Metal | Diallyl Phthalate (DAP) | Unshielded | Flange | N | Olive Drab Chromate over Cadmium | Olive Drab | Copper Alloy | Male Pins Receptacle | Silver | 24-7 | 16 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 97.68 | |
| 10 | $ 89.64 | |||
| 25 | $ 86.19 | |||
| 50 | $ 83.32 | |||
| 100 | $ 78.72 | |||
Description
General part information
97-3102A24 Series
16 Position Circular Connector Receptacle, Female Sockets Solder Cup
