TEN 25-4812

Traco Power

DC DC CONVERTER 12V 30W

Search across all available documentation for this part.

Traco Power

DC DC CONVERTER 12V 30W

Technical Specifications

Parameters and characteristics for this part

Isolated DC/DC Converters - Through Hole

Part	Features	Voltage - Isolation	Voltage - Input (Min) [Min]	Package / Case	Number of Outputs	Applications	Voltage - Output 1	Current - Output (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Type	Mounting Type	Power (Watts)	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)
Traco Power TEN 25-1212	OCP OVP Remote On/Off SCP	1.5 kV	9 V	7-DIP Module 6 Leads	1	ITE (Commercial)	12 V	2.5 A	40.6 mm	50.8 mm	9.5 mm	1.6 "	0.37 in	2 in	18 V	85 °C	-40 °C	88 %	Isolated Module	Through Hole	30 W
Traco Power TEN 25-4812	OCP OVP Remote On/Off SCP	1.5 kV	48 V	7-DIP Module 6 Leads	1	ITE (Commercial)	12 V	2.5 A	40.6 mm	50.8 mm	9.5 mm	1.6 "	0.37 in	2 in	75 V	85 °C	-40 °C	89 %	Isolated Module	Through Hole	30 W
Traco Power TEN 25-2423	OCP OVP Remote On/Off SCP	1.5 kV	18 V	7-DIP Module	2	ITE (Commercial)	15 V		40.6 mm	50.8 mm	9.5 mm	1.6 "	0.37 in	2 in	36 V	85 °C	-40 °C	89 %	Isolated Module	Through Hole	30 W	-15 V	1 A	1 A
Traco Power TEN 25-4812WI	OTP OVP Remote On/Off SCP UVLO	1.5 kV	18 V	7-DIP Module 6 Leads	1	ITE (Commercial)	12 V	2.5 A	40.6 mm	50.8 mm	9.3 mm	1.6 "	0.37 in	2 in	75 V	85 °C	-40 °C	89 %	Isolated Module	Through Hole	30 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated DC/DC Converters - Through Hole
