450-10-268-00-006101
ActivePRECI-DIP SA
CONN HEADER VERT 68POS 2.54MM
Deep-Dive with AI
Search across all available documentation for this part.
450-10-268-00-006101
ActivePRECI-DIP SA
CONN HEADER VERT 68POS 2.54MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 450-10-268-00-006101 |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating | 10 çin |
| Contact Finish Thickness - Mating | 0.25 çm |
| Contact Finish Thickness - Post | 10 çin |
| Contact Finish Thickness - Post | 0.25 çm |
| Contact Length - Mating | 0.141 in |
| Contact Length - Mating | 3.6 mm |
| Contact Length - Post | 0.114 in |
| Contact Length - Post | 2.9 mm |
| Contact Material | Brass |
| Contact Shape | Circular |
| Contact Type | Male Pin |
| Current Rating (Amps) | 3 A |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Insulation Material | Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 68 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Overall Contact Length | 10 mm |
| Overall Contact Length | 0.394 in |
| Pitch - Mating | 0.1 in |
| Pitch - Mating | 2.54 mm |
| Row Spacing - Mating [x] | 2.54 mm |
| Row Spacing - Mating [x] | 0.1 in |
| Shrouding | Unshrouded |
| Termination | Solder |
| Voltage Rating | 150 VDC |
450-10 Series
...
| Part | Shrouding | Voltage Rating | Insulation Material | Number of Positions | Current Rating (Amps) | Contact Type | Mounting Type | Contact Material | Contact Length - Post | Contact Length - Post | Contact Shape | Termination | Contact Finish - Post | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Number of Rows | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Material Flammability Rating | Contact Length - Mating | Contact Length - Mating | Connector Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Overall Contact Length | Overall Contact Length | Contact Finish - Mating | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 68 | 3 A | Male Pin | Through Hole | Brass | 0.114 in | 2.9 mm | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | 10 mm | 0.394 in | Gold | |
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 64 | 3 A | Male Pin | Through Hole | Brass | 0.164 in | 4.17 mm | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.156 in | 3.96 mm | Header | 10 çin | 0.25 çm | 12.12 mm | 0.477 in | Gold | |
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 14 | 3 A | Male Pin | Through Hole | Brass | 0.121 in | 3.08 mm | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.134 " | 3.39 mm | Header | 10 çin | 0.25 çm | 10.57 mm | 0.416 in | Gold | |
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 46 | 3 A | Male Pin | Surface Mount | Brass | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | Gold | |||||
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 62 | 3 A | Male Pin | Surface Mount | Brass | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | Gold | |||||
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 38 | 3 A | Male Pin | Through Hole | Brass | 0.121 in | 3.08 mm | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.134 " | 3.39 mm | Header | 10 çin | 0.25 çm | 10.57 mm | 0.416 in | Gold | |
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 60 | 3 A | Male Pin | Surface Mount | Brass | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | Gold | |||||
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 8 | 3 A | Male Pin | Surface Mount | Brass | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | Gold | Pick and Place | ||||
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 70 | 3 A | Male Pin | Through Hole | Brass | 0.121 in | 3.08 mm | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.134 " | 3.39 mm | Header | 10 çin | 0.25 çm | 10.57 mm | 0.416 in | Gold | |
PRECI-DIP SA | Unshrouded | 150 VDC | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 4 | 3 A | Male Pin | Surface Mount | Brass | Circular | Solder | Gold | All | 0.1 in | 2.54 mm | 2 | 2.54 mm | 0.1 in | Push-Pull | -55 °C | 125 °C | 10 çin | 0.25 çm | Black | UL94 V-0 | 0.141 in | 3.6 mm | Header | 10 çin | 0.25 çm | Gold |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 80 | $ 9.61 | |
Description
General part information
450-10 Series
Connector Header Through Hole 68 position 0.100" (2.54mm)
