450-10-270-00-013101

Active

PRECI-DIP SA

CONN HEADER VERT 70POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

450-10-270-00-013101

Active

PRECI-DIP SA

CONN HEADER VERT 70POS 2.54MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	450-10-270-00-013101

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Finish Thickness - Post	10 çin
Contact Finish Thickness - Post	0.25 çm
Contact Length - Mating	0.134 "
Contact Length - Mating	3.39 mm
Contact Length - Post	0.121 in
Contact Length - Post	3.08 mm
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	70
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Overall Contact Length	10.57 mm
Overall Contact Length	0.416 in
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Shrouding	Unshrouded
Termination	Solder
Voltage Rating	150 VDC

450-10 Series

...

Part	Shrouding	Voltage Rating	Insulation Material	Number of Positions	Current Rating (Amps)	Contact Type	Mounting Type	Contact Material	Contact Length - Post	Contact Length - Post	Contact Shape	Termination	Contact Finish - Post	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Number of Rows	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Color	Material Flammability Rating	Contact Length - Mating	Contact Length - Mating	Connector Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Overall Contact Length	Overall Contact Length	Contact Finish - Mating	Features
PRECI-DIP SA 450-10-268-00-006101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	68	3 A	Male Pin	Through Hole	Brass	0.114 in	2.9 mm	Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm	10 mm	0.394 in	Gold
PRECI-DIP SA 450-10-264-00-001101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	64	3 A	Male Pin	Through Hole	Brass	0.164 in	4.17 mm	Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.156 in	3.96 mm	Header	10 çin	0.25 çm	12.12 mm	0.477 in	Gold
PRECI-DIP SA 450-10-214-00-013101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	14	3 A	Male Pin	Through Hole	Brass	0.121 in	3.08 mm	Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.134 "	3.39 mm	Header	10 çin	0.25 çm	10.57 mm	0.416 in	Gold
PRECI-DIP SA 450-10-246-00-106101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	46	3 A	Male Pin	Surface Mount	Brass			Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm			Gold
PRECI-DIP SA 450-10-262-00-106101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	62	3 A	Male Pin	Surface Mount	Brass			Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm			Gold
PRECI-DIP SA 450-10-238-00-013101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	38	3 A	Male Pin	Through Hole	Brass	0.121 in	3.08 mm	Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.134 "	3.39 mm	Header	10 çin	0.25 çm	10.57 mm	0.416 in	Gold
PRECI-DIP SA 450-10-260-01-899101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	60	3 A	Male Pin	Surface Mount	Brass			Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm			Gold
PRECI-DIP SA 450-10-208-01-899191	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	8	3 A	Male Pin	Surface Mount	Brass			Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm			Gold	Pick and Place
PRECI-DIP SA 450-10-270-00-013101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	70	3 A	Male Pin	Through Hole	Brass	0.121 in	3.08 mm	Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.134 "	3.39 mm	Header	10 çin	0.25 çm	10.57 mm	0.416 in	Gold
PRECI-DIP SA 450-10-204-01-899101	Unshrouded	150 VDC	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	4	3 A	Male Pin	Surface Mount	Brass			Circular	Solder	Gold	All	0.1 in	2.54 mm	2	2.54 mm	0.1 in	Push-Pull	-55 °C	125 °C	10 çin	0.25 çm	Black	UL94 V-0	0.141 in	3.6 mm	Header	10 çin	0.25 çm			Gold

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	70	$ 11.11

Description

General part information

450-10 Series

Connector Header Through Hole 70 position 0.100" (2.54mm)
