Technical Specifications
Parameters and characteristics for this part
| Specification | ZMCJF7P0T |
|---|---|
| Actuator Type | Round (Pin Plunger) |
| Circuit | SPDT |
| Current Rating (Amps) | 3 A |
| Electrical Life | 15000 Cycles |
| Mounting Type | Through Hole |
| Operating Force | 150 gf |
| Operating Position [x] | 0.276 in |
| Operating Position [x] | 7 mm |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -30 ░C |
| Switch Function | On-Mom |
| Termination Style | PC Pin |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 2.03 | |
| 10 | $ 1.87 | |||
| 25 | $ 1.75 | |||
| 40 | $ 1.72 | |||
| 80 | $ 1.37 | |||
Description
General part information
Zm0 Series Series
Designers of PCB detection switches, communication devices and testing equipment turn to the ZM series from C&K because of their reputation for being reliable and long-lasting. The ZM series is a mini size snap-acting switch that features a reliable snap-acting mechanism, compact size and the long electrical and mechanical life that today’s applications require.
