1241.2821

Active

SCHURTER Inc.

SWITCH: VANDAL RESISTANT; POS: 2; SPST-NO; 0.125A/48VDC; IP67

Search across all available documentation for this part.

Active

SCHURTER Inc.

SWITCH: VANDAL RESISTANT; POS: 2; SPST-NO; 0.125A/48VDC; IP67

Technical Specifications

Parameters and characteristics for this part

Specification	1241.2821

Actuator Marking	No Marking
Actuator Type	Flush, Button, Round
Circuit	SPST-NO
Color - Actuator/Cap	Silver
Current Rating (Amps)	125 mA
Electrical Life	1000000 Cycles
Features	Tactile Feedback
Ingress Protection	IP65 - Dust Tight, Water Resistant
Mechanical Life	1000000 Cycles
Mounting Type	Panel Mount, Front
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-25 °C
Panel Cutout Dimensions [diameter]	19 mm
Switch Function	Off-Mom
Termination Style	Solder Lug
Type	Anti-Vandal
Voltage Rating - DC	48 V

Pushbutton Switches MCS 19 Metallic Ag

Part	Termination Style	Mounting Type	Panel Cutout Dimensions [diameter]	Mechanical Life	Type	Current Rating (Amps)	Color - Actuator/Cap	Voltage Rating - DC	Circuit	Features	Ingress Protection	Switch Function	Actuator Type	Operating Temperature [Min]	Operating Temperature [Max]	Electrical Life	Actuator Marking
SCHURTER Inc. 1241.2807	Connector	Panel Mount Front	19 mm	1000000 Cycles	Anti-Vandal	125 mA	Silver	48 V	SPST-NO	Tactile Feedback	IP65 - Dust Tight Water Resistant	Off-Mom	Button Flush Round	-20 C	60 °C	1000000 Cycles	No Marking
SCHURTER Inc. 1241.2821	Solder Lug	Panel Mount Front	19 mm	1000000 Cycles	Anti-Vandal	125 mA	Silver	48 V	SPST-NO	Tactile Feedback	IP65 - Dust Tight Water Resistant	Off-Mom	Button Flush Round	-25 °C	60 °C	1000000 Cycles	No Marking

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pushbutton Switches MCS 19 Metallic Ag
