SMP1302-085LF

Active

Skyworks Solutions Inc.

RF DIODE PIN 200V 3W 3QFN

Search across all available documentation for this part.

Active

Skyworks Solutions Inc.

RF DIODE PIN 200V 3W 3QFN

Technical Specifications

Parameters and characteristics for this part

Part	Resistance @ If, F	Capacitance @ Vr, F	Supplier Device Package	Voltage - Peak Reverse (Max) [Max]	Power Dissipation (Max) [Max]	Package / Case	Diode Type	Operating Temperature [Min]	Operating Temperature [Max]	Power Dissipation (Max)	Current - Max [Max]	Frequency [Max]	Frequency [Min]	Contents	Type	Utilized IC / Part
Skyworks Solutions Inc. SMP1302-079LF	1.5 Ohm	0.3 pF	SC-79	200 V	250 mW	SC-79 SOD-523	PIN - Single	-65 °C	150 °C
Skyworks Solutions Inc. SMP1302-085LF	1.5 Ohm	0.35 pF	3-QFN (2x2)	200 V		2-VDFN Exposed Pad	PIN - Single	-40 °C	150 °C	3 W	1.5 A
Skyworks Solutions Inc. SMP1302-078LF	1.5 Ohm	0.3 pF	SC-88	200 V	250 mW	6-TSSOP SC-88 SOT-363	PIN - 2 Pair Common Cathode	-65 °C	150 °C
Skyworks Solutions Inc. SMP1302-085LF-EVB												6 GHz	10 MHz	Board(s)	PIN Diode	SMP1302-085LF
Skyworks Solutions Inc. SMP1302-003LF	1.5 Ohm	0.3 pF	SOT-23-3	200 V	250 mW	SC-59 SOT-23-3 TO-236-3	PIN - 1 Pair Common Anode	-65 °C	150 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF Diode PIN - Single 200V 1.5 A 3 W 3-QFN (2x2)
