Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	78M6610+LMU/D01

Input Impedance [Max]	90 kOhm
Input Impedance [Min]	30 kOhm
Meter Type	Single Phase
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	24-WFQFN Exposed Pad
Supplier Device Package	24-TQFN (4x4)
Voltage - I/O High	2 V
Voltage - I/O Low	0.8 V
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	3 V

78M6610 Series

Part	Mounting Type	Voltage - I/O Low	Package / Case	Meter Type	Input Impedance [Max]	Input Impedance [Min]	Voltage - I/O High	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Min]	Voltage - Supply [Max]	Supplier Device Package	Type	Function	Utilized IC / Part	Supplied Contents	Contents	Package / Case [x]	Package / Case [y]
Analog Devices Inc./Maxim Integrated 78M6610+LMU/B01	Surface Mount	0.8 V	24-WFQFN Exposed Pad	Single Phase	90 kOhm	30 kOhm	2 V	85 °C	-40 °C	3 V	3.6 V	24-TQFN (4x4)
Analog Devices Inc./Maxim Integrated 78M6610+PSD/C02T
Analog Devices Inc./Maxim Integrated 78M6610+PSU/EK#1													Power Management	Energy/Power Meter	78M6610	Board(s)	Board(s)
Analog Devices Inc./Maxim Integrated 78M6610+PSU/C00	Surface Mount	0.5 V 0.8 V	16-TSSOP	Single Phase	90 kOhm	30 kOhm	0.6 V 2 V	85 °C	-40 °C	3 V	3.6 V	16-TSSOP						0.173 in	4.4 mm
Analog Devices Inc./Maxim Integrated 78M6610+LMUEVK1#													Power Management	Energy/Power Meter	78M6610	Board(s)
Analog Devices Inc./Maxim Integrated 78M6610+PSU/C09	Surface Mount	0.5 V 0.8 V	16-TSSOP	Single Phase	90 kOhm	30 kOhm	0.6 V 2 V	85 °C	-40 °C	3 V	3.6 V	16-TSSOP						0.173 in	4.4 mm
Analog Devices Inc./Maxim Integrated 78M6610+PSU/C09T	Surface Mount	0.5 V 0.8 V	16-TSSOP	Single Phase	90 kOhm	30 kOhm	0.6 V 2 V	85 °C	-40 °C	3 V	3.6 V	16-TSSOP						0.173 in	4.4 mm
Analog Devices Inc./Maxim Integrated 78M6610+LMU/EK#1													Power Management	Energy/Power Meter	78M6610	Board(s)
Analog Devices Inc./Maxim Integrated 78M6610+LMU/D01	Surface Mount	0.8 V	24-WFQFN Exposed Pad	Single Phase	90 kOhm	30 kOhm	2 V	85 °C	-40 °C	3 V	3.6 V	24-TQFN (4x4)
Analog Devices Inc./Maxim Integrated 78M6610+PSD/B02T

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

78M6610 Series

Single Phase Meter IC 24-TQFN (4x4)
