TRI 6-2412

Active

Traco Power

DC DC CONVERTER 12V 6W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER 12V 6W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Isolation	Mounting Type	Voltage - Output 2	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Number of Outputs	Type	Applications	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Approval Agency	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Efficiency	Package / Case	Current - Output (Max)	Current - Output (Max)	Voltage - Output 1	Current - Output (Max) [Max]
Traco Power TRI 6-2422	9 kV	Through Hole	-12 V	-40 °C	203 °F	6 W	2	Isolated Module	ITE (Commercial)	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	CB cURus	36 V	18 V	86 %	24-DIP Module 6 Leads	250 mA	250 mA	12 V
Traco Power TRI 6-2412	9 kV	Through Hole		-40 °C	203 °F	6 W	1	Isolated Module	ITE (Commercial)	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	CB cURus	36 V	18 V	86 %	24-DIP Module 5 Leads			12 V	500 mA
Traco Power TRI 6-4822	9 kV	Through Hole	-12 V	-40 °C	203 °F	6 W	2	Isolated Module	ITE (Commercial)	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	CB cURus	75 V	36 V	87 %	24-DIP Module 6 Leads	250 mA	250 mA	12 V
Traco Power TRI 6-1223	9 kV	Through Hole	-15 V	-40 °C	203 °F	6 W	2	Isolated Module	ITE (Commercial)	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	CB cURus	18 V	9 V	87 %	24-DIP Module 6 Leads			15 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 12V 500mA 18V - 36V Input
