FR20204HBDN

Active

METZ CONNECT USA Inc.

RECEPTACLE, THR, DUAL ROW, .100"

Search across all available documentation for this part.

Active

METZ CONNECT USA Inc.

RECEPTACLE, THR, DUAL ROW, .100"

Technical Specifications

Parameters and characteristics for this part

Specification	FR20204HBDN

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	Flash
Contact Length - Post	0.114 in
Contact Length - Post	2.9 mm
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Female Socket
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.197 in
Insulation Height	5 mm
Insulation Material	Polyethylene Terephthalate (PET), Polyester
Mounting Type	Through Hole, Right Angle
Number of Positions	8
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Termination	Solder

Part	Contact Shape	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height [z]	Insulation Height [z]	Mounting Type	Number of Rows	Number of Positions Loaded	Fastening Type	Termination	Contact Finish Thickness - Mating	Connector Type	Number of Positions	Contact Type	Contact Length - Post	Contact Length - Post	Insulation Material	Insulation Color	Pitch - Mating	Pitch - Mating	Contact Material	Insulation Height	Insulation Height	Row Spacing - Mating [x]	Row Spacing - Mating [x]
METZ CONNECT USA Inc. FR20204HBNN	Square	Gold	-40 °C	105 ░C	0.094 in	2.39 mm	Through Hole Right Angle	1	All	Push-Pull	Solder	Flash	Receptacle	4	Female Socket	0.114 in	2.9 mm	Polyester Polyethylene Terephthalate (PET)	Black	0.1 in	2.54 mm	Copper Alloy
METZ CONNECT USA Inc. FR20204HBDN	Square	Gold	-40 °C	105 ░C			Through Hole Right Angle	2	All	Push-Pull	Solder	Flash	Receptacle	8	Female Socket	0.114 in	2.9 mm	Polyester Polyethylene Terephthalate (PET)	Black	0.1 in	2.54 mm	Copper Alloy	0.197 in	5 mm	2.54 mm	0.1 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

8 Position Receptacle Connector 0.100" (2.54mm) Through Hole, Right Angle Gold
