K85X-ED-9S-BRJ

Active

Kycon, Inc.

CONN D-SUB RCPT 9POS VERT SOLDER

Search across all available documentation for this part.

Active

Kycon, Inc.

CONN D-SUB RCPT 9POS VERT SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	K85X-ED-9S-BRJ

Color	Black
Connector Style	D-Sub
Connector Type	Receptacle, Female Sockets
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Form	Stamped
Contact Material	Brass
Contact Type	Signal
Current Rating (Amps)	2 A
Dielectric Material	Polybutylene Terephthalate (PBT), Glass Filled
Flange Feature	Board Side (4-40), Mating Side, Female Screwlock (4-40)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	9
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Shell Material, Finish	Nickel Plated, Steel
Shell Size, Connector Layout [custom]	DE, E
Shell Size, Connector Layout [custom]	1
Termination	Solder
Voltage Rating	30 VDC

Part	Contact Finish	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Number of Positions	Voltage Rating	Termination	Material Flammability Rating	Flange Feature	Current Rating (Amps)	Contact Form	Connector Type	Shell Material, Finish	Connector Style	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Mounting Type	Contact Type	Number of Rows	Color	Contact Finish Thickness	Contact Finish Thickness	Dielectric Material	Contact Finish Thickness
Kycon, Inc. K85X-ED-9S-BR30	Gold	105 ░C	-55 °C	Brass	9	30 VDC	Solder	UL94 V-0	4-40 Board Side	2 A	Stamped	Receptacle Female Sockets	Nickel Plated Steel	D-Sub	DE E	1	Through Hole	Signal	2	Black	0.76 Ám	30 Áin	Polybutylene Terephthalate (PBT) Glass Filled
Kycon, Inc. K85X-ED-9S-BRJ	Gold	105 ░C	-55 °C	Brass	9	30 VDC	Solder	UL94 V-0	Board Side (4-40) Mating Side Female Screwlock (4-40)	2 A	Stamped	Receptacle Female Sockets	Nickel Plated Steel	D-Sub	DE E	1	Through Hole	Signal	2	Black			Polybutylene Terephthalate (PBT) Glass Filled	Flash
Kycon, Inc. K85X-ED-9S-KJ30	Gold	105 ░C	-55 °C	Brass	9	30 VDC	Solder	UL94 V-0	Board Side (4-40) Mating Side Female Screwlock (4-40)	2 A	Stamped	Receptacle Female Sockets	Nickel Plated Steel	D-Sub	DE E	1	Through Hole	Signal	2	Black	0.76 Ám	30 Áin	Polybutylene Terephthalate (PBT) Glass Filled
