HWS300-24/HD
ActiveTDK-LAMBDA
AC/DC CONVERTER 24V 300W
Deep-Dive with AI
Search across all available documentation for this part.
HWS300-24/HD
ActiveTDK-LAMBDA
AC/DC CONVERTER 24V 300W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | HWS300-24/HD |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output 1 | 14 A |
| Efficiency | 85 % |
| Features | Remote On/Off, Remote Sense, Universal Input, Adjustable Output, DC Input Capable, Load Sharing |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 300 W |
| Size / Dimension [x] | 165.1 mm |
| Size / Dimension [x] | 6.5 in |
| Size / Dimension [y] | 2.4 " |
| Size / Dimension [y] | 61 mm |
| Size / Dimension [z] | 82 mm |
| Size / Dimension [z] | 3.23 in |
| Type | Conformal Coated, Enclosed |
| Voltage - Input [Max] | 265 VAC |
| Voltage - Input [Min] | 85 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 541.51 | |
| 10 | $ 486.69 | |||
Description
General part information
HWS300-1500 Series
Switching Power Supplies 336W 24V 14A
