R222941324
ActiveRadiall USA, Inc.
CONN MMCX RCP CRIMP RA CABLE MOUNT
Deep-Dive with AI
Search across all available documentation for this part.
R222941324
ActiveRadiall USA, Inc.
CONN MMCX RCP CRIMP RA CABLE MOUNT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | R222941324 |
|---|---|
| Body Finish | Gold |
| Body Material | Bronze |
| Center Contact Material | Beryllium Copper |
| Center Contact Plating | Gold |
| Connector Type | Male Pin, Receptacle |
| Contact Termination | Solder |
| Dielectric Material | Polyetheretherketone (PEEK) |
| Fastening Type | Snap-On |
| Features | Non-Magnetic, Limited Detent |
| Frequency - Max [Max] | 12.4 GHz |
| Housing Color | Gold |
| Impedance | 50 Ohms |
| Mounting Type | Surface Mount |
| Number of Ports | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Shield Termination | Solder |
| Voltage Rating | 335 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 8.36 | |
| 10 | $ 7.56 | |||
| 25 | $ 7.14 | |||
| 50 | $ 6.97 | |||
| 100 | $ 6.62 | |||
| 250 | $ 5.92 | |||
| Digi-Reel® | 1 | $ 8.36 | ||
| 10 | $ 7.56 | |||
| 25 | $ 7.14 | |||
| 50 | $ 6.97 | |||
| 100 | $ 6.62 | |||
| 250 | $ 5.92 | |||
| Tape & Reel (TR) | 500 | $ 5.58 | ||
| 1000 | $ 4.88 | |||
| 1500 | $ 4.77 | |||
Description
General part information
R22294 Series
SMP Connector Receptacle, Male Pin 50 Ohms Surface Mount Solder
Documents
Technical documentation and resources
No documents available
