325210-08-0
ActiveCurtis Industries
CONN BARRIER STRIP 8CIRC 0.325"
Deep-Dive with AI
Search across all available documentation for this part.
325210-08-0
ActiveCurtis Industries
CONN BARRIER STRIP 8CIRC 0.325"
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 325210-08-0 |
|---|---|
| Barrier Type | 3 Wall (Tri) |
| Bottom Termination | PC Pin |
| Current Rating (Amps) | 15 A |
| Features | Flange |
| Material - Insulation | Polypropylene (PP) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Chassis, Panel, Through Hole |
| Number of Circuits [custom] | 8 |
| Number of Rows | 1 |
| Number of Wire Entries | 8 |
| Operating Temperature | 105 C |
| Pitch [x] | 8.26 mm |
| Pitch [x] | 0.325 in |
| Terminal Block Type | Barrier Block |
| Terminal Screw Material | Steel |
| Top Termination | Screws |
| Voltage Rating | 300 VDC |
| Wire Gauge [Max] | 22 AWG |
| Wire Gauge [Min] | 14 AWG |
325210 Series
| Part | Mounting Type | Material Flammability Rating | Terminal Block Type | Top Termination | Current Rating (Amps) | Barrier Type | Number of Rows | Wire Gauge [Min] | Wire Gauge [Max] | Operating Temperature | Bottom Termination | Pitch [x] | Pitch [x] | Terminal Screw Material | Voltage Rating | Material - Insulation | Features | Number of Wire Entries | Number of Circuits | Number of Circuits [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 9 | ||
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 2 | 2 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 8 | 8 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 12 | 12 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 15 | 15 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 16 | 16 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 3 | 3 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 20 | 20 | |
Curtis Industries | Chassis Panel Through Hole | UL94 V-0 | Barrier Block | Screws | 15 A | 3 Wall (Tri) | 1 | 14 AWG | 22 AWG | 105 C | PC Pin | 8.26 mm | 0.325 in | Steel | 300 VDC | Polypropylene (PP) | Flange | 5 | 5 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.84 | |
| 10 | $ 3.81 | |||
| 30 | $ 3.63 | |||
| 50 | $ 3.29 | |||
| 100 | $ 3.27 | |||
Description
General part information
325210 Series
8 Circuit 0.325" (8.26mm) Barrier Block Connector Screws
