8616-310023

Active

STORM INTERFACE

KEYPAD, SF6000 SERIES, 4 X 4, MATRIX, 50 MA, 24 V

Search across all available documentation for this part.

Active

STORM INTERFACE

KEYPAD, SF6000 SERIES, 4 X 4, MATRIX, 50 MA, 24 V

Technical Specifications

Parameters and characteristics for this part

Specification	8616-310023

Approval Agency	CE, cURus
Contact Rating @ Voltage	0.05 A, 24 VDC
Features	Anti-Vandal
Illumination	Non-Illuminated
Ingress Protection	IP65 - Dust Tight, Water Resistant
Key Color	Multiple
Key Type	Metal
Legend	Telephone Format, Function Keys
Legend Color	Black
Legend Type	Fixed
Matrix (Columns x Rows) [custom]	4
Matrix (Columns x Rows) [custom]	4
Mounting Type	Panel Mount, Front or Rear
Number of Keys	16
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 C
Operational Life	4000000 Cycles
Output Type	1.81 mOhm
Panel Cutout Dimensions [x]	97 mm
Panel Cutout Dimensions [y]	79 mm
Switch Type	Conductive Rubber
Termination Style	Pin Header

Part	Legend Type	Matrix (Columns x Rows) [custom]	Matrix (Columns x Rows) [custom]	Operational Life	Illumination	Approval Agency	Key Type	Ingress Protection	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Number of Keys	Switch Type	Contact Rating @ Voltage	Output Type	Termination Style	Mounting Type	Legend Color	Legend	Key Color	Operating Temperature [Min]	Operating Temperature [Max]	Features	Illumination Voltage (Nominal)
STORM INTERFACE 8616-210023	Fixed	4	4	4000000 Cycles	Non-Illuminated	CE cURus	Polymer	IP65 - Dust Tight Water Resistant	79 mm	97 mm	16	Conductive Rubber	0.05 A 24 VDC	1.81 mOhm	Pin Header	Panel Mount Front or Rear	Black White	Function Keys Telephone Format	Multiple	-20 C	60 °C
STORM INTERFACE 8616-310023	Fixed	4	4	4000000 Cycles	Non-Illuminated	CE cURus	Metal	IP65 - Dust Tight Water Resistant	79 mm	97 mm	16	Conductive Rubber	0.05 A 24 VDC	1.81 mOhm	Pin Header	Panel Mount Front or Rear	Black	Function Keys Telephone Format	Multiple	-20 C	60 °C	Anti-Vandal
STORM INTERFACE 8616-410023	Fixed	4	4	4000000 Cycles	Illuminated	CE cURus	Transparent Key Cap	IP65 - Dust Tight Water Resistant	79 mm	97 mm	16	Conductive Rubber	0.05 A 24 VDC	1.81 mOhm	Pin Header	Panel Mount Front or Rear	Black	Function Keys Telephone Format	Translucent	-20 C	60 °C		5 VDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	5	$ 146.26
Newark	Each	1	$ 159.29
		5	$ 151.33

General part information

Keypad Switch 16 Metal Keys Conductive Rubber Contacts Matrix Output Non-Illuminated 0.05A @ 24VDC
