SR4L034-EVB-4

Active

Antenova

INVERSA LEFT EVALUATION BOARD

Search across all available documentation for this part.

Active

Antenova

INVERSA LEFT EVALUATION BOARD

Technical Specifications

Parameters and characteristics for this part

Specification	SR4L034-EVB-4

For Use With/Related Products	SR4L034
Frequency [Max]	960 MHz, 2.4 GHz, 2.17 GHz, 2.7 GHz
Frequency [Min]	2.5 GHz, 1.71 GHz, 2.3 GHz, 698 MHz
Supplied Contents	Board(s)
Type	Antenna

Part	Termination	Mounting Type	VSWR	Number of Bands	Applications	Return Loss	Height (Max) [Max] [z]	Height (Max)	Antenna Type	Frequency Range [Max]	Frequency Range [Min]	Frequency (Center/Band)	Frequency Group	RF Family/Standard	Frequency [Min]	Frequency [Max]	Type	Supplied Contents	For Use With/Related Products
Antenova SR4L034-L	Solder	Surface Mount	2.5 2.8 3.5 3.7	4	3G 4G CDMA DCS EDGE GPRS GSM HSPA IMT LTE PCS UMTS WCDMA	-7 dB -6.6 dB -6 dB -5.1 dB -4.9 dB	0.13 in	3.3 mm	PCB Trace	2.17 GHz 2.4 GHz 2.69 GHz 798 MHz 960 MHz	1.71 GHz 2.3 GHz 2.5 GHz 698 MHz 824 MHz	1.94 GHz 2.35 GHz 2.595 GHz 829 MHz	Wide Band	Cellular
Antenova SR4L034-R	Solder	Surface Mount	2.5 2.8 3.5 3.7	4	3G 4G CDMA DCS EDGE GPRS GSM HSPA IMT LTE PCS UMTS WCDMA	-7 dB -6.6 dB -6 dB -5.1 dB -4.9 dB	0.13 in	3.3 mm	PCB Trace	2.17 GHz 2.4 GHz 2.69 GHz 798 MHz 960 MHz	1.71 GHz 2.3 GHz 2.5 GHz 698 MHz 824 MHz	1.94 GHz 2.35 GHz 2.595 GHz 829 MHz	Wide Band	Cellular
Antenova SR4L034-EVB-4															1.71 GHz 2.3 GHz 2.5 GHz 698 MHz	2.17 GHz 2.4 GHz 2.7 GHz 960 MHz	Antenna	Board(s)	SR4L034

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 68.75

General part information

- SR4L034 Antenna 698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.4GHz, 2.5GHz ~ 2.7GHz Evaluation Board
