BAV20W RHG

Active

Taiwan Semiconductor Corporation

DIODE GP 250V 200MA SOD123F

Search across all available documentation for this part.

Active

Taiwan Semiconductor Corporation

DIODE GP 250V 200MA SOD123F

Technical Specifications

Parameters and characteristics for this part

Specification	BAV20W RHG

Capacitance @ Vr, F	5 pF
Current - Average Rectified (Io)	200 mA
Current - Reverse Leakage @ Vr	100 nA
Mounting Type	Surface Mount
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-65 C
Package / Case	SOD-123F
Reverse Recovery Time (trr)	50 ns
Speed	Any Speed
Speed	200 mA
Supplier Device Package	SOD-123F
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	250 V
Voltage - Forward (Vf) (Max) @ If	1.25 V

Part	Supplier Device Package	Current - Reverse Leakage @ Vr	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Mounting Type	Technology	Reverse Recovery Time (trr)	Speed	Speed	Voltage - Forward (Vf) (Max) @ If	Capacitance @ Vr, F	Voltage - DC Reverse (Vr) (Max) [Max]	Package / Case	Current - Average Rectified (Io)
Taiwan Semiconductor Corporation BAV20W RHG	SOD-123F	100 nA	150 °C	-65 C	Surface Mount	Standard	50 ns	Any Speed	200 mA	1.25 V	5 pF	250 V	SOD-123F	200 mA
Taiwan Semiconductor Corporation BAV20WS-G RRG	SOD-323	100 nA	150 °C	-65 C	Surface Mount	Standard	50 ns	Any Speed	200 mA	1.25 V	5 pF		SC-76 SOD-323	200 mA
Taiwan Semiconductor Corporation BAV20W-G RHG	SOD-123	100 nA	150 °C	-65 C	Surface Mount	Standard	50 ns	Any Speed	200 mA	1.25 V	5 pF		SOD-123	200 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode 250 V 200mA Surface Mount SOD-123F
