IRM-30-24ST

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 24V 31W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

IRM-30-24ST

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 24V 31W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	IRM-30-24ST

Applications	ITE (Commercial)
Approval Agency	CB, CE, cURus, TUV
Current - Output 1	1.3 A
Efficiency	88.5 %
Features	Universal Input
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-30 °C
Power (Watts)	31 W
Size / Dimension [x]	3.58 in
Size / Dimension [x]	91 mm
Size / Dimension [y]	1.56 in
Size / Dimension [y]	39.5 mm
Size / Dimension [z]	28.5 mm
Size / Dimension [z]	1.12 in
Type	Enclosed
Voltage - Input [Max]	305 VAC
Voltage - Input [Min]	85 VAC
Voltage - Isolation	3000 V
Voltage - Output 1	24 V

IRM-30 Series

Part	Type	Voltage - Output 1	Number of Outputs	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Current - Output 1	Mounting Type	Voltage - Input [Min]	Voltage - Input [Max]	Features	Approval Agency	Applications	Efficiency	Power (Watts)	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Load Regulation	Current - Output (Max) [Max]	Line Regulation
MEAN WELL USA Inc. IRM-30-24ST	Enclosed	24 V	1	3.58 in	28.5 mm	1.56 in	39.5 mm	1.12 in	91 mm	1.3 A	Chassis Mount	85 VAC	305 VAC	Universal Input	CB CE cURus TUV	ITE (Commercial)	88.5 %	31 W	3000 V	70 °C	-30 °C
MEAN WELL USA Inc. IRM-30-12ST	Enclosed	12 V	1	3.58 in	28.5 mm	1.56 in	39.5 mm	1.12 in	91 mm	2.5 A	Chassis Mount			Universal Input	CB CE cURus TUV	ITE (Commercial)	88 %	30 W	3000 V	70 °C	-30 °C
MEAN WELL USA Inc. IRM-30-15ST	Enclosed	15 V	1	3.58 in	28.5 mm	1.56 in	39.5 mm	1.12 in	91 mm	2 A	Chassis Mount			Universal Input	CB CE cURus TUV	ITE (Commercial)	88 %	30 W	3000 V	70 °C	-30 °C
MEAN WELL USA Inc. IRM-30-5	Enclosed	5 V	1	2.74 "	24 mm	1.54 "	39 mm	0.94 in	69.5 mm		Through Hole			Universal Input	CB CE cURus TUV	ITE (Commercial)	83 %	30 W		70 °C	-30 °C	4-DIP Module	1 %	6 A	0.5 %
MEAN WELL USA Inc. IRM-30-48	Enclosed	48 V	1	2.74 "	24 mm	1.54 "	39 mm	0.94 in	69.5 mm		Through Hole			Universal Input	CB CE cURus TUV	ITE (Commercial)	90 %	30 W		70 °C	-30 °C	4-DIP Module	0.5 %	630 mA	0.5 %
MEAN WELL USA Inc. IRM-30-12	Enclosed	12 V	1	2.74 "	24 mm	1.54 "	39 mm	0.94 in	69.5 mm		Through Hole			Universal Input	CB CE cURus TUV	ITE (Commercial)	88 %	30 W		70 °C	-30 °C	4-DIP Module	0.5 %	2.5 A	0.5 %

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 17.92
		5	$ 16.89
		10	$ 16.46
		25	$ 15.91

Description

General part information

IRM-30 Series

Enclosed AC DC Converters 1 Output 24V 85 ~ 305 VAC Input
