BAT-HLD-009-SMT-TR
ActiveTE Connectivity Linx
BATTERY HOLDER AA SMD
Deep-Dive with AI
Search across all available documentation for this part.
BAT-HLD-009-SMT-TR
ActiveTE Connectivity Linx
BATTERY HOLDER AA SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BAT-HLD-009-SMT-TR |
|---|---|
| Battery Cell Size | AA |
| Battery Type, Function | Cylindrical, Contact (Single) |
| Height Above Board | 0.25 in |
| Height Above Board | 6.35 mm |
| Mounting Type | PCB, Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Termination Style | SMD (SMT) Tab |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.48 | |
| 10 | $ 1.25 | |||
| 50 | $ 1.10 | |||
| 100 | $ 1.03 | |||
| Digi-Reel® | 1 | $ 1.48 | ||
| 10 | $ 1.25 | |||
| 50 | $ 1.10 | |||
| 100 | $ 1.03 | |||
| Tape & Reel (TR) | 320 | $ 0.53 | ||
| 640 | $ 0.50 | |||
| 1600 | $ 0.47 | |||
Description
General part information
BAT-HLD Series
Battery AA Cell SMD (SMT) Tab
Documents
Technical documentation and resources
No documents available
