RF55-28E-T-00-50-G-SH
ActiveAdam Tech
CONN SMB PLUG PCB 50OHM SOLDER
Deep-Dive with AI
Search across all available documentation for this part.
RF55-28E-T-00-50-G-SH
ActiveAdam Tech
CONN SMB PLUG PCB 50OHM SOLDER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | RF55-28E-T-00-50-G-SH |
|---|---|
| Body Finish | Gold |
| Body Material | Brass |
| Center Contact Material | Brass |
| Center Contact Plating | Gold |
| Connector Style | SMB, Fakra |
| Connector Type | Male Pin, Plug |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Locking Ramp |
| Features | Code E |
| Frequency - Max [Max] | 4 GHz |
| Housing Color | Green |
| Impedance | 50 Ohms |
| Mounting Type | Through Hole |
| Number of Ports | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Shield Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 5.81 | |
| 10 | $ 4.44 | |||
| 25 | $ 4.01 | |||
Description
General part information
RF55-28 Series
SMB, Fakra Connector Plug, Male Pin 50 Ohms Through Hole Solder
