499-V3-250-10-009101

Active

PRECI-DIP SA

CONN HEADER R/A 50POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

499-V3-250-10-009101

Active

PRECI-DIP SA

CONN HEADER R/A 50POS 2.54MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	499-V3-250-10-009101

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	29.5 Áin
Contact Finish Thickness - Mating	0.75 Ám
Contact Length - Mating	4 mm
Contact Length - Mating	0.157 in
Contact Length - Post	3.2 mm
Contact Length - Post [x]	0.126 in
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle
Number of Positions	50
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Shrouding	Unshrouded
Termination	Solder
Voltage Rating	150 VDC

499-V3 Series

Part	Insulation Material	Contact Length - Post	Contact Length - Post [x]	Contact Shape	Contact Finish - Mating	Mounting Type	Insulation Color	Fastening Type	Number of Rows	Shrouding	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Number of Positions Loaded	Current Rating (Amps)	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Type	Contact Material	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Contact Length - Mating	Contact Length - Mating	Termination	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating
PRECI-DIP SA 499-V3-266-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	66	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-234-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	34	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-232-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám		All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-222-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	22 positions	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-230-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	30	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-206-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	6	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-254-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	54	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-244-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	44	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-250-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	50	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC
PRECI-DIP SA 499-V3-228-10-009101	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	3.2 mm	0.126 in	Circular	Gold	Through Hole Right Angle	Black	Push-Pull	2	Unshrouded	Header	29.5 Áin	0.75 Ám	28	All	3 A	2.54 mm	0.1 in	Male Pin	Brass	Tin	0.1 in	2.54 mm	4 mm	0.157 in	Solder	UL94 V-0	-55 °C	125 °C	150 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	128	$ 8.63

Description

General part information

499-V3 Series

Connector Header Through Hole, Right Angle 50 position 0.100" (2.54mm)

Documents

Technical documentation and resources

No documents available
