CFM-4020V-070-255

Active

CUI Devices

FAN AXIAL 40X20MM 5VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CFM-4020V-070-255

Active

CUI Devices

FAN AXIAL 40X20MM 5VDC WIRE

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CFM-4020V-070-255

Air Flow	8.9 CFM
Air Flow	0.249 mł/min
Approval Agency	cURus, CE, TUV
Current Rating (Amps)	0.173 A
Fan Type	Tubeaxial
Features	Auto Restart
Lifetime @ Temp.	70000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	25.5 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	870 mW
RPM	7000 RPM
Size / Dimension	Square
Size / Dimension [x]	40 mm
Size / Dimension [z]	40 mm
Static Pressure	0.22 in H2O
Static Pressure	54.8 Pa
Termination	2 Wire Leads
Voltage - Rated	5 V
Voltage Range [Max]	6 VDC
Voltage Range [Min]	3.5 VDC
Weight	29.03 g
Weight	0.064 lb
Width [y]	20 mm

CFM-4020 Series

Part	Voltage Range [Min]	Voltage Range [Max]	Approval Agency	Width [y]	Weight	Weight	Air Flow	Air Flow	Noise	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Static Pressure	Static Pressure	Termination	Lifetime @ Temp.	Size / Dimension [z]	Size / Dimension	Size / Dimension [x]	Power (Watts)	Fan Type	Current Rating (Amps)	Features	Material - Blade	RPM	Voltage - Rated	Air Flow	Air Flow
CUI Devices CFM-4020V-150-165-20	4.5 V	13.8 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	0.176 m³/min	6.3 CFM	16.5 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.11 in H2O	27.4 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	560 mW	Tubeaxial	46 mA	Auto Restart Speed Sensor (Tach)	Polybutylene Terephthalate (PBT)	5000 RPM	12 VDC
CUI Devices CFM-4020V-280-275			CE cURus TUV	20 mm	29.03 g	0.064 lb	0.302 mł/min	10.8 CFM	27.5 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.29 in H2O	72.2 Pa	2 Wire Leads	70000 Hrs	40 mm	Square	40 mm	1.08 W	Tubeaxial	45 mA	Auto Restart	Polybutylene Terephthalate (PBT)	8000 RPM	24 VDC
CUI Devices CFM-4020V-070-255-20	3.5 VDC	6 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	0.249 mł/min	8.9 CFM	25.5 dB	70 °C	70 °C	-10 °C	-10 °C	0.22 in H2O	54.8 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	870 mW	Tubeaxial	0.173 A	Auto Restart Speed Sensor (Tach)	Polybutylene Terephthalate (PBT)	7000 RPM	5 V
CUI Devices CFM-4020V-260-210			CE cURus TUV	20 mm	29.03 g	0.064 lb	0.216 m³/min	7.7 CFM	21 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.17 in H2O	42.3 Pa	2 Wire Leads	70000 Hrs	40 mm	Square	40 mm	720 mW	Tubeaxial	30 mA	Auto Restart	Polybutylene Terephthalate (PBT)	6000 RPM	24 VDC
CUI Devices CFM-4020V-145-123-20	4.5 V	13.8 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	5.5 CFM		12.3 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.1 in H2O	24.9 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	460 mW	Tubeaxial	0.038 A	Auto Restart Speed Sensor (Tach)	Polybutylene Terephthalate (PBT)	4500 RPM	12 VDC	0.154 m³/min
CUI Devices CFM-4020V-145-123-11	4.5 V	13.8 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	5.5 CFM		12.3 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.1 in H2O	24.9 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	460 mW	Tubeaxial	0.038 A	Auto Restart Locked Rotor Sensor	Polybutylene Terephthalate (PBT)	4500 RPM	12 VDC	0.154 m³/min
CUI Devices CFM-4020V-280-275-11			CE cURus TUV	20 mm	29.03 g	0.064 lb			27.5 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.29 in H2O	72.2 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	1.08 W	Tubeaxial	45 mA	Auto Restart Locked Rotor Sensor	Polybutylene Terephthalate (PBT)	8000 RPM	24 VDC
CUI Devices CFM-4020V-160-210-20	4.5 V	13.8 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	0.216 m³/min		21 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.17 in H2O	42.3 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	0.65 W	Tubeaxial	0.054 A	Auto Restart Speed Sensor (Tach)	Polybutylene Terephthalate (PBT)	6000 RPM	12 VDC		7.7 CFM
CUI Devices CFM-4020V-070-255	3.5 VDC	6 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb	0.249 mł/min	8.9 CFM	25.5 dB	70 °C	70 °C	-10 °C	-10 °C	0.22 in H2O	54.8 Pa	2 Wire Leads	70000 Hrs	40 mm	Square	40 mm	870 mW	Tubeaxial	0.173 A	Auto Restart	Polybutylene Terephthalate (PBT)	7000 RPM	5 V
CUI Devices CFM-4020V-180-275-20	4.5 V	13.8 VDC	CE cURus TUV	20 mm	29.03 g	0.064 lb			27.5 dB(A)	70 °C	70 °C	-10 °C	-10 °C	0.29 in H2O	72.2 Pa	3 Wire Leads	70000 Hrs	40 mm	Square	40 mm	1.11 W	Tubeaxial	0.092 A	Auto Restart Speed Sensor (Tach)	Polybutylene Terephthalate (PBT)	8000 RPM	12 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	600	$ 6.66

Description

General part information

CFM-4020 Series

Fan Tubeaxial 5VDC Square - 40mm L x 40mm H omniCOOL™ Magnetic Sleeve 8.9 CFM (0.249m³/min) 2 Wire Leads
