CLM2C-ACA-CYBA0343

Obsolete

Cree LED

SMD LM2-C SERIES LED -AMBER COLOR,3550-7100MCD,HUE FROM A3 TO A4,TAPE & REEL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CLM2C-ACA-CYBA0343

Obsolete

Cree LED

SMD LM2-C SERIES LED -AMBER COLOR,3550-7100MCD,HUE FROM A3 TO A4,TAPE & REEL

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CLM2C-ACA-CYBA0343

Color	Amber
Configuration	Standard
Current - Test	20 mA
Height (Max) [Max] [z]	3.86 mm
Lens Size [diameter]	2.45 mm
Lens Style	Round with Domed Top
Millicandela Rating	5325 mcd
Mounting Type	Surface Mount
Package / Case	4-PLCC
Size / Dimension [x]	3.2 mm
Size / Dimension [y]	2.8 mm
Supplier Device Package	4-PLCC
Voltage - Forward (Vf) (Typ)	2 V
Wavelength - Dominant	590 nm

CLM2C Series

Part	Height (Max) [Max] [z]	Wavelength - Dominant	Voltage - Forward (Vf) (Typ)	Color	Lens Style	Configuration	Size / Dimension [y]	Size / Dimension [x]	Current - Test	Mounting Type	Package / Case	Lens Size [diameter]	Millicandela Rating	Supplier Device Package
Cree LED CLM2C-ACA-CYBA0343	3.86 mm	590 nm	2 V	Amber	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	5325 mcd	4-PLCC
Cree LED CLM2C-GCA-CYBB0793	3.86 mm	528 nm	3.2 V	Green	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	6275 mcd	4-PLCC
Cree LED CLM2C-ACA-CYAA0253	3.86 mm	590 nm	2 V	Amber	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	4950 mcd	4-PLCC
Cree LED CLM2C-RCA-CYAZ0BB3	3.86 mm	622 nm	2 V	Red	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	4200 mcd	4-PLCC
Cree LED CLM2C-RCA-CXBZ0BB3	3.86 mm	622 nm	2 V	Red	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	3920 mcd	4-PLCC
Cree LED CLM2C-RCA-CWBZ0BB3	3.86 mm	622 nm	2 V	Red	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	3500 mcd	4-PLCC
Cree LED CLM2C-BCA-CWAXB353	3.86 mm	468 nm	3.2 V	Blue	Round with Domed Top	Standard	2.8 mm	3.2 mm	20 mA	Surface Mount	4-PLCC	2.45 mm	1960 mcd	4-PLCC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.31
		10	$ 0.29
		100	$ 0.27
		1000	$ 0.24
	Digi-Reel®	1	$ 0.31
		10	$ 0.29
		100	$ 0.27
		1000	$ 0.24
	Tape & Reel (TR)	2300	$ 0.24

Description

General part information

CLM2C Series

SMD LEDs is packaged in the industry standard package. These LEDs have high reliability performance and are designed to work under a wide range of environmental conditions. This high reliability feature makes them ideally suited to be used under ArchitectSize (mm):3.2 x 2.8 • Color and Typical Dominant Wavelength: Red (619 - 624nm) Amber(584 - 596nm) • Luminous Intensity (mcd) CLM2C-RCA:(1400 - 5600) CLM2C-ACA:(1800 - 7100) • Moisture Sensitivity Level: 5a • Lead-Free • RoHS Compliant
