M83513/01-GC

Active

Cinch Connectivity Solutions Trompeter

D SUB CONNECTOR, MICRO D, PLUG, MIL-DTL-83513 SERIES, 51 CONTACTS, SOLDER CUP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsTechnical Data Sheet EN

M83513/01-GC

Active

Cinch Connectivity Solutions Trompeter

D SUB CONNECTOR, MICRO D, PLUG, MIL-DTL-83513 SERIES, 51 CONTACTS, SOLDER CUP

Deep-Dive with AI

DocumentsTechnical Data Sheet EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M83513/01-GC

Connector Style	Micro-D, D-Type
Connector Type	Plug, Male Pins
Contact Finish	Gold
Contact Finish Thickness	50 µin
Contact Finish Thickness	1.27 µm
Contact Material	Copper Alloy
Contact Type	Signal
Current Rating (Amps)	3 A
Dielectric Material	Polyester, Glass Filled
Flange Feature	Housing/Shell (Unthreaded)
Material Flammability Rating	UL94 V-0
Number of Positions	51
Number of Rows	3
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Shell Material, Finish	Yellow Chromate Plated Cadmium, Aluminum Alloy
Shell Size, Connector Layout [custom]	0.05
Shell Size, Connector Layout [custom]	0.05

M83513/01 Series

Part	Contact Finish Thickness	Contact Finish Thickness	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Connector Type	Dielectric Material	Contact Type	Number of Positions	Connector Style	Contact Finish	Current Rating (Amps)	Shell Material, Finish	Material Flammability Rating	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Flange Feature	Number of Rows
Cinch Connectivity Solutions Trompeter M83513/01-GC	50 µin	1.27 µm	-55 °C	125 °C	Copper Alloy	Male Pins Plug	Polyester Glass Filled	Signal	51	D-Type Micro-D	Gold	3 A	Aluminum Alloy Yellow Chromate Plated Cadmium	UL94 V-0	0.05	0.05	Housing/Shell (Unthreaded)	3
Cinch Connectivity Solutions Trompeter M83513/01-CN	50 µin	1.27 µm	-55 °C	125 °C	Copper Alloy	Male Pins Plug	Polyester Glass Filled	Signal	21	D-Type Micro-D	Gold	3 A	Aluminum Alloy Electroless Nickel Plated	UL94 V-0	0.05	0.043	Housing/Shell (Unthreaded)	2
Cinch Connectivity Solutions Trompeter M83513/01-AC	50 µin	1.27 µm	-55 °C	125 °C	Copper Alloy	Male Pins Plug	Polyester Glass Filled	Signal	9	D-Type Micro-D	Gold	3 A	Aluminum Alloy Yellow Chromate Plated Cadmium	UL94 V-0	0.05	0.043	Housing/Shell (Unthreaded)	2
Cinch Connectivity Solutions Trompeter M83513/01-BN	50 µin	1.27 µm	-55 °C	125 °C	Copper Alloy	Male Pins Plug	Polyester Glass Filled	Signal	15	D-Type Micro-D	Gold	3 A	Aluminum Alloy Electroless Nickel Plated	UL94 V-0	0.05	0.043	Housing/Shell (Unthreaded)	2
Cinch Connectivity Solutions Trompeter M83513/01-BC	50 µin	1.27 µm	-55 °C	125 °C	Copper Alloy	Male Pins Plug	Polyester Glass Filled	Signal	15	D-Type Micro-D	Gold	3 A	Aluminum Alloy Yellow Chromate Plated Cadmium	UL94 V-0	0.05	0.043	Housing/Shell (Unthreaded)	2

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 157.84
		10	$ 134.18
		25	$ 125.79
		50	$ 119.92
	Bulk	1	$ 1001.33
		1	$ 224.06
		10	$ 190.48
		25	$ 178.57
		50	$ 175.93
Newark	Each	1	$ 171.74
		10	$ 162.14
		25	$ 152.55
		50	$ 143.91

Description

General part information

M83513/01 Series

51 Position D-Type, Micro-D Plug, Male Pins Connector

Documents

Technical documentation and resources

Technical Data Sheet EN

Datasheet
