KIT38081

Active

Amphenol Socapex

CONN MOD PLUG 8P8C SHIELDED

Search across all available documentation for this part.

Active

Amphenol Socapex

CONN MOD PLUG 8P8C SHIELDED

Technical Specifications

Parameters and characteristics for this part

Specification	KIT38081

Cable Type	Round Cable, Not Specified
Color	Olive
Connector Type	Plug
Features	Circular Threaded Coupling
Housing Material	Aluminum
Ingress Protection	IP68 - Dust Tight, Waterproof
Length [x]	54 mm
Length [x]	2.126 "
Number of Positions/Contacts	8p8c (RJ45, Ethernet)
Ratings	Cat5e
Shielding	Shielded
Termination	IDC

Part	Number of Rows	Tab Direction	Number of Ports	Termination	LED Color	Orientation	Features	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Number of Positions/Contacts	Ingress Protection	Mounting Type	Shielding	Ratings	Cable Type	Color	Housing Material	Length [x]	Length [x]
Amphenol Socapex KIT38082NI	1	User Selectable	1	PC Board Solder	Does Not Contain LED	Straight	Circular Threaded Coupling Heat Shrink Tubing	85 °C	-40 °C	Jack	8p8c (RJ45 Ethernet)	IP68 - Dust Tight Waterproof	Panel Mount Square Flange	Shielded
Amphenol Socapex KIT38081				IDC			Circular Threaded Coupling			Plug	8p8c (RJ45 Ethernet)	IP68 - Dust Tight Waterproof		Shielded	Cat5e	Round Cable Not Specified	Olive	Aluminum	54 mm	2.126 "
Amphenol Socapex KIT38204	1	User Selectable	1	Solder	Does Not Contain LED	Straight	Circular Threaded Coupling Heat Shrink Tubing	85 °C	-40 °C	Jack	8p8c (RJ45 Ethernet)	IP68 - Dust Tight Waterproof	Bulkhead Panel Mount	Shielded	Cat5e
Amphenol Socapex KIT38204NI	1	User Selectable	1	Solder	Does Not Contain LED	Straight	Circular Threaded Coupling Heat Shrink Tubing	85 °C	-40 °C	Jack	8p8c (RJ45 Ethernet)	IP68 - Dust Tight Waterproof	Bulkhead Panel Mount	Shielded	Cat5e
Amphenol Socapex KIT38204ZC	1	User Selectable	1	Solder	Does Not Contain LED	Straight	Circular Threaded Coupling Heat Shrink Tubing	85 °C	-40 °C	Jack	8p8c (RJ45 Ethernet)	IP68 - Dust Tight Waterproof	Bulkhead Panel Mount	Shielded	Cat5e

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Plug Modular Connector 8p8c (RJ45, Ethernet) Position Shielded Cat5e IDC
