OP265WPS
ActiveTT Electronics/Optek Technology
EMITTER IR 850NM 50MA T-1
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OP265WPS
ActiveTT Electronics/Optek Technology
EMITTER IR 850NM 50MA T-1
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | OP265WPS |
|---|---|
| Current - DC Forward (If) (Max) [Max] | 50 mA |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Orientation | Top View |
| Package / Case | T-1 |
| Type | Infrared (IR) |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 1.8 V |
| Wavelength | 850 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.86 | |
| 100 | $ 1.75 | |||
| 250 | $ 1.69 | |||
| 500 | $ 1.64 | |||
| 1000 | $ 1.58 | |||
| 2500 | $ 1.52 | |||
| 5000 | $ 1.51 | |||
Description
General part information
OP265 Series
Infrared (IR) Emitter 850nm 1.8V 50mA 120° T-1
