THB1248CE

Active

Delta Electronics

FAN AXIAL 120X38MM 48VDC WIRE

Search across all available documentation for this part.

Active

Delta Electronics

FAN AXIAL 120X38MM 48VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	THB1248CE

Air Flow	7.34 m³/min
Air Flow	262 CFM
Approval Agency	cURus, CE, TUV
Bearing Type	Ball
Current Rating (Amps)	0.95 A
Fan Type	Tubeaxial
Features	Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Lifetime @ Temp.	70000 Hrs
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	70 dB(A)
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	45.6 W
RPM	7800 RPM
Size / Dimension [x]	120 mm
Size / Dimension [y]	120 mm
Static Pressure	2.03 in H2O
Static Pressure	505.7 Pa
Termination	4 Wire Leads
Voltage - Rated [custom]	48 VDC
Voltage Range [Max]	60 V
Voltage Range [Min]	36 VDC
Weight	0.915 lb
Weight	415.04 g
Width [y]	38 mm

Part	Fan Type	Approval Agency	Termination	Noise	Voltage - Rated [custom]	RPM	Air Flow	Air Flow	Features	Lifetime @ Temp.	Static Pressure	Static Pressure	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Weight	Weight	Voltage Range [Max]	Voltage Range [Min]	Bearing Type	Material - Blade	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	Current Rating (Amps)	Material - Frame	Width [y]	Ingress Protection
Delta Electronics THB1248CE	Tubeaxial	CE cURus TUV	4 Wire Leads	70 dB(A)	48 VDC	7800 RPM	7.34 m³/min	262 CFM	Locked Rotor Protection PWM Control Speed Sensor (Tach)	70000 Hrs	2.03 in H2O	505.7 Pa	70 °C	70 °C	-10 °C	-10 °C	0.915 lb	415.04 g	60 V	36 VDC	Ball	Plastic	120 mm	120 mm	45.6 W	0.95 A	Aluminum	38 mm
Delta Electronics THB1248B-AXHG	Tubeaxial	CE cURus TUV	4 Wire Leads	59 dB(A)	48 VDC	5300 RPM	5.22 m³/min	186.6 CFM	Locked Rotor Protection PWM Control Speed Sensor (Tach)	70000 Hrs	0.962 in H2O	239.6 Pa	70 °C	70 °C	-10 °C	-10 °C	0.437 lb	198 g	75 VDC	36 VDC	Ball	Plastic	120 mm	120 mm	19.2 W	400 mA	Plastic	25.4 mm	IP54 - Dust Protected Water Resistant
Delta Electronics THB1248B-A	Tubeaxial	CE cURus TUV	4 Wire Leads	59 dB(A)	48 VDC	5300 RPM	5.22 m³/min	186.6 CFM	Locked Rotor Protection PWM Control Speed Sensor (Tach)	70000 Hrs	0.962 in H2O	239.6 Pa	70 °C	70 °C	-10 °C	-10 °C	0.437 lb	198 g	75 VDC	36 VDC	Ball	Plastic	120 mm	120 mm	19.2 W	400 mA	Plastic	25.4 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 262.0 CFM (7.34m³/min) 4 Wire Leads
