81-01-14215-2000

Active

Parker Chomerics

RFI FINGERSTOCK BECU UNPLAT ADH

Search across all available documentation for this part.

Active

Parker Chomerics

RFI FINGERSTOCK BECU UNPLAT ADH

Technical Specifications

Parameters and characteristics for this part

Part	Height [z]	Height [z]	Length [x]	Length [x]	Plating	Width [x]	Width	Material	Attachment Method	Type	Operating Temperature [Min]	Operating Temperature [Max]	Width	Width [x]	Length	Length
Parker Chomerics 81-01-14215-2000	0.13 in	3.3 mm	457 mm	17.992 in	Unplated	0.37 in	9.4 mm	Beryllium Copper	Non-Conductive Adhesive	Fingerstock	-40 °C	121 °C
Parker Chomerics 81-01-32AS1-2000	0.22 in	5.59 mm	457 mm	17.992 in	Unplated		15.24 mm	Beryllium Copper	Non-Conductive Adhesive	Fingerstock	-40 °C	121 °C	0.6 in
Parker Chomerics 81-01-14309-2000	0.22 in	5.59 mm			Unplated	0.561 in		Beryllium Copper	Non-Conductive Adhesive	Fingerstock	-40 °C	121 °C		14.24 mm	15.748 in	400 mm
Parker Chomerics 81-01-14618-2000	0.1 in	2.54 mm	406 mm	15.984 "	Unplated	0.3 "	7.62 mm	Beryllium Copper	Non-Conductive Adhesive	Fingerstock	-40 °C	121 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	250	$ 22.28
