20TQC22MYFB

Active

Panasonic Industrial Automation Sales

CAP TANT POLY 22UF 20V 1411

Search across all available documentation for this part.

Active

Panasonic Industrial Automation Sales

CAP TANT POLY 22UF 20V 1411

Technical Specifications

Parameters and characteristics for this part

Specification	20TQC22MYFB

Capacitance	22 µF
ESR (Equivalent Series Resistance)	80 mOhm
Features	General Purpose
Height - Seated (Max) [Max] [z]	2 mm
Height - Seated (Max) [Max] [z]	0.079 in
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	B2
Mounting Type	Surface Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Package / Case	1411
Package / Case	3528 Metric
Size / Dimension [x]	0.138 "
Size / Dimension [x]	3.5 mm
Size / Dimension [y]	0.11 in
Size / Dimension [y]	2.8 mm
Tolerance	20 %
Type	Molded
Voltage - Rated	20 V

Part	Mounting Type	Features	Voltage - Rated	Lifetime @ Temp.	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Type	Manufacturer Size Code	Capacitance	Package / Case	Package / Case	ESR (Equivalent Series Resistance)	Operating Temperature [Min]	Operating Temperature [Max]	Tolerance	Package / Case	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max)	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales 20TQC22MYFB	Surface Mount	General Purpose	20 V	2000 Hrs	2 mm	0.079 in	0.11 in	2.8 mm	0.138 "	3.5 mm	Molded	B2	22 µF	1411	3528 Metric	80 mOhm	-55 °C	105 ░C	20 %
Panasonic Industrial Automation Sales 20TQC33MYFD	Surface Mount	General Purpose	20 V	2000 Hrs	2 mm	0.079 in		4.3 mm		7.3 mm	Molded	D2	33 ÁF		7343 Metric	80 mOhm	-55 °C	105 ░C	20 %	2917	0.287 "	0.169 "
Panasonic Industrial Automation Sales 20TQC22MYFD	Surface Mount	General Purpose	20 V	2000 Hrs	2 mm	0.079 in		4.3 mm		7.3 mm	Molded	D2	22 µF		7343 Metric	80 mOhm	-55 °C	105 ░C	20 %	2917	0.287 "	0.169 "
Panasonic Industrial Automation Sales 20TQC100MD2	Surface Mount	General Purpose	20 V	2000 Hrs	2 mm	0.079 in		4.3 mm		7.3 mm	Molded	D2	100 µF		7343 Metric	100 mOhm	-55 °C	105 ░C	20 %	2917	0.287 "	0.169 "
Panasonic Industrial Automation Sales 20TQC100MYF	Surface Mount	General Purpose	20 V	2000 Hrs				4.3 mm		7.3 mm	Molded	D3L	100 µF		7343 Metric	55 mOhm	-55 °C	105 ░C	20 %	2917	0.287 "	0.169 "	2.9 mm	0.114 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

22 çF Molded Tantalum Polymer Capacitor 20 V 1411 (3528 Metric) 80mOhm @ 100kHz
