TSRN 1-0525SM

Active

Traco Power

DC DC CONVERTER 2.5V 2.5W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER 2.5V 2.5W

Technical Specifications

Parameters and characteristics for this part

Specification	TSRN 1-0525SM

Applications	ITE (Commercial)
Current - Output (Max) [Max]	1 A
Efficiency	95.5 %
Features	Remote On/Off, SCP, OTP
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	10-SMD Module, 6 Leads
Size / Dimension [x]	0.6 in
Size / Dimension [x]	15.2 mm
Size / Dimension [y]	9.3 mm
Size / Dimension [y]	0.37 "
Size / Dimension [z]	0.29 "
Size / Dimension [z]	7.4 mm
Type	Linear Regulator Replacement
Voltage - Input (Max) [Max]	5.5 V
Voltage - Input (Min) [Min]	3 V
Voltage - Output 1	2.5 V

Part	Number of Outputs	Voltage - Output 1	Voltage - Input (Max) [Max]	Type	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Efficiency	Power (Watts)	Package / Case	Current - Output (Max) [Max]	Features	Voltage - Input (Min) [Min]
Traco Power TSRN 1-24150	1	15 V	36 V	Linear Regulator Replacement	Through Hole	85 °C	-40 °C	ITE (Commercial)	10.2 mm	0.46 in	0.3 "	0.4 "	11.7 mm	7.5 mm	95 %	15 W	3-SIP Module	1 A	OTP SCP	16.5 V
Traco Power TSRN 1-0525SM	1	2.5 V	5.5 V	Linear Regulator Replacement	Surface Mount	85 °C	-40 °C	ITE (Commercial)	7.4 mm	0.6 in	0.37 "	0.29 "	15.2 mm	9.3 mm	95.5 %		10-SMD Module 6 Leads	1 A	OTP Remote On/Off SCP	3 V
Traco Power TSRN 1-24120A	1	12 V	36 V	Linear Regulator Replacement	Through Hole	85 °C	-40 °C	ITE (Commercial)	7.5 mm	0.46 in	0.4 in	0.3 "	11.7 mm	10.2 mm	95 %	12 W	3-SIP Module	1 A	OTP SCP	13.5 V
Traco Power TSRN 1-2415	1	1.5 V	36 V	Linear Regulator Replacement	Through Hole	85 °C	-40 °C	ITE (Commercial)	10.2 mm	0.46 in	0.3 "	0.4 "	11.7 mm	7.5 mm	77 %	1.5 W	3-SIP Module	1 A	OTP SCP	4.6 V
Traco Power TSRN 1-24120	1	12 V	36 V	Linear Regulator Replacement	Through Hole	85 °C	-40 °C	ITE (Commercial)	10.2 mm	0.46 in	0.3 "	0.4 "	11.7 mm	7.5 mm	95 %	12 W	3-SIP Module	1 A	OTP SCP	13.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Linear Regulator Replacement DC DC Converter 1 Output 2.5V 1A 3V - 5.5V Input
