M83513/03-G03C

Active

Cinch Connectivity Solutions Trompeter

CABLE ASSY D-MIC-D 51P 457.2MM

Deep-Dive with AI

Search across all available documentation for this part.

M83513/03-G03C

Active

Cinch Connectivity Solutions Trompeter

CABLE ASSY D-MIC-D 51P 457.2MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M83513/03-G03C

1st Connector	Plug, Male Pins
2nd Connector	Individual Wire Leads
Color	Multiple, Individual
Contact Finish	Gold
Contact Finish Thickness	50 µin
Contact Finish Thickness	1.27 µm
Length [x]	457.2 mm
Length [x]	1.5 ft
Number of Positions	51
Type	D-Type, Micro-D

M83513/03 Series

Part	Contact Finish Thickness	Contact Finish Thickness	Length [x]	Length [x]	Color	Type	2nd Connector	Number of Positions	Contact Finish	1st Connector
Cinch Connectivity Solutions Trompeter M83513/03-A03N	50 µin	1.27 µm	457.2 mm	1.5 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	9	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-C12C	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	21	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-H12N	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	100	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-G03N	50 µin	1.27 µm	457.2 mm	1.5 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	51	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-D04N	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads		Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-B12C	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	15	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-C04N	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	21	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-F03N	50 µin	1.27 µm	457.2 mm	1.5 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	37	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-F12N	50 µin	1.27 µm	914.4 mm	3 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	37	Gold	Plug Male Pins
Cinch Connectivity Solutions Trompeter M83513/03-G03C	50 µin	1.27 µm	457.2 mm	1.5 ft	Individual Multiple	D-Type Micro-D	Individual Wire Leads	51	Gold	Plug Male Pins

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 198.34
		10	$ 155.17
		25	$ 141.54
		50	$ 132.36
	Bulk	1	$ 1363.08

Description

General part information

M83513/03 Series

D-Sub Cable Assembly D-Type, Micro-D Multiple, Individual 1.50' (457.20mm) Plug, Male Pins to Individual Wire Leads

Documents

Technical documentation and resources

No documents available
