SS28W2T

Active

Amphenol Sine Systems Corp

SOCKET CONTACT, STAMPED, TIN PLA

Search across all available documentation for this part.

Active

Amphenol Sine Systems Corp

SOCKET CONTACT, STAMPED, TIN PLA

Technical Specifications

Parameters and characteristics for this part

Part	Contact Finish Thickness	Contact Material	Type	Contact Finish	Contact Type	Features	Contact Termination	Termination Finish	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Contact Size	Contact Finish Thickness	Contact Finish Thickness
Amphenol Sine Systems Corp SS28W1F	Flash	Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp	Copper Alloy	0.08 mm²	0.05 mm²	20
Amphenol Sine Systems Corp SS28W1T		Copper Alloy	Signal Stamped	Tin	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20
Amphenol Sine Systems Corp SS28W2T		Copper Alloy	Stamped	Tin	Socket		Crimp	Nickel	0.08 mm²	0.05 mm²	20
Amphenol Sine Systems Corp SS28W1G30		Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20	0.76 Ám	30 Áin
Amphenol Sine Systems Corp SS28W1G15		Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20	0.38 µm	15 µin
Amphenol Sine Systems Corp SS28W2G5		Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20	0.127 µm	5 µin
Amphenol Sine Systems Corp SS28W2G10		Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20	0.25 Ám	10 Áin
Amphenol Sine Systems Corp SS28W2F	Flash	Copper Alloy	Signal Stamped	Gold	Socket	Insulation Support	Crimp		0.08 mm²	0.05 mm²	20

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	12000	$ 0.30

General part information

Socket Contact 28-30 AWG Size 20 Crimp Tin

Technical documentation and resources
