GSD09002SEU
ActiveAmphenol ICC (Commercial Products)
CONN MICRO SD CARD PUSH-PUSH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
GSD09002SEU
ActiveAmphenol ICC (Commercial Products)
CONN MICRO SD CARD PUSH-PUSH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | GSD09002SEU |
|---|---|
| Card Type | Secure Digital - SD |
| Connector Type | Connector and Ejector |
| Contact Finish | Gold |
| Features | Switch, Board Guide |
| Height Above Board [z] | 0.106 in |
| Height Above Board [z] | 2.7 mm |
| Insertion, Removal Method | Push Out, Push In |
| Mounting Feature | Normal, Standard - Top |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 11 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.94 | |
| 10 | $ 1.76 | |||
| 25 | $ 1.66 | |||
| 50 | $ 1.63 | |||
| 100 | $ 1.55 | |||
| Digi-Reel® | 1 | $ 1.94 | ||
| 10 | $ 1.76 | |||
| 25 | $ 1.66 | |||
| 50 | $ 1.63 | |||
| 100 | $ 1.55 | |||
| Tape & Reel (TR) | 250 | $ 1.36 | ||
Description
General part information
GSD0900 Series
11 (9 + 2) Position Card Connector Secure Digital - SD Surface Mount, Right Angle Gold
Documents
Technical documentation and resources
