1-1589072-2
ActiveTE Connectivity Aerospace, Defense and Marine
CONNECTORSRF COAX CONNECTORSRF C
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-1589072-2 |
|---|---|
| Connector Type | Receptacle |
| Contact Material | Brass |
| Contact Shape | Circular |
| Insulation Height | 0.166 in |
| Insulation Height | 4.22 mm |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Pitch - Mating | 0.1 in |
| Pitch - Mating | 2.54 mm |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 433.62 | |
| 2 | $ 417.26 | |||
| 13 | $ 409.08 | |||
| 25 | $ 346.14 | |||
| 50 | $ 314.68 | |||
| 100 | $ 293.69 | |||
| 250 | $ 272.71 | |||
Description
General part information
1589072 Series
3 Position Receptacle Connector 0.100" (2.54mm) Surface Mount, Right Angle
